2200 020 001 Single Cylinder, Air Compressor

Name: 2200 020 001 Single Cylinder, Air Compressor
Brand: Vaden Original
SKU: 2200 020 001

2200 020 001

Summary

●Cylinder Bore: Ø92.00 ●Stroke: 54 mm ●Swept Volume: 360cm³ ●Air Inlet Port: 7/8’’-14 UNF ●Air Outlet Port: 3/16’’-12 UN ●Number of Cylinders: 1 ●Through Drive: ✓ ●Air Unloader Port: 1/8’’-27 NPT ●Water (W) or Air (A) Cooled: W ●Water Inlet Port: 3/4’’-16 UNF ●Water Outlet Port: 3/4’’-16 UNF ●With ESS Feature: ✓ ●Water Cooled Valve Plate: ✓ ●Weight: 21,5 KG

EAN Code	8699031068626

Ready to Order

Get Information

Compatible OEM Codes

CATERPILLAR 255-4160 223-3637 223-3636 191-6521 10R-1437 0R-1624 0R-1623
BENDIX 5014428 5012533 5012532 5011441 5011427 5010806 5010803

Description

VADEN ORIGINAL 2200 020 001 in the Single Cylinder, Air Compressor group is an OE-quality equivalent to the original CATERPILLAR (0R1623, 0R1624, 10R1437, 1916521, 2233636, 2233637, 2554160), BENDIX (5010803, 5010806, 5011427, 5011441, 5012532, 5012533, 5014428) references and ensures safe use on heavy commercial vehicles. VADEN ORIGINAL offers solutions with more than 12475 products across 16 categories.

Technical Specifications

Cylinder Bore	Ø92.00
Stroke	54 mm
Swept Volume	360cm³
Air Inlet Port	7/8’’-14 UNF
Air Outlet Port	3/16’’-12 UN
Number of Cylinders	1
Through Drive	OK
Air Unloader Port	1/8’’-27 NPT
Water (W) or Air (A) Cooled	W
Water Inlet Port	3/4’’-16 UNF
Water Outlet Port	3/4’’-16 UNF
With ESS Feature	OK
Water Cooled Valve Plate	OK
Weight	21,5 KG
