1600 010 001 Twin Cylinder, Air Compressor
2050 Visualized

1600 010 001 DAF Twin Cylinder, Air Compressor

1600 010 001

Summary

●Cylinder Bore: Ø75.00 ●Stroke: 50 mm ●Swept Volume: 442cm³ ●Air Inlet Port: M26x1,5 ●Air Outlet Port: M26x1,5 ●Number of Cylinders: 2 ●Through Drive: OK ●Air Unloader Port: M12x1,5 ●Water (W) or Air (A) Cooled: W ●Water Inlet Port: M14x1,5 ●Water Outlet Port: M14x1,5 ●With ESS Feature: OK ●Weight: 19,3 KG

EAN Code8699031047751
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Compatible OEM Codes

  • WABCO 911 504 503 7 911 504 503 0 911 504 501 7 911 504 501 0 911 504 500 7 911 504 500 0
  • DAF 1451651 1310523R 1310523A 1310523

Description

The precision engineering of this twin cylinder air compressor ensures reliable pneumatic pressure for heavy commercial vehicle systems. Designed with a high-strength component structure, it maintains consistent performance under demanding operating conditions within the air brake system.

This component is the OE equivalent of the DAF 1310523 and WABCO 9115045000 used in DAF 95XF, CF85, CF75, F75, and F95 models. It is also compatible with DAF 1310523A, 1310523R, 1451651 and WABCO 9115045007, 9115045010, 9115045030, 9115045037, 9115045017 and WABCO 911504503. The product is engineered to meet strict industrial standards for durability and precision.

The assembly features a Ø75.00 cylinder bore and a 5{mm} stroke with a swept volume of 442cm³. It utilizes M26x1,5 ports for both air inlet and outlet, alongside an M12x1,5 unloader port. The unit is water-cooled (W) and includes a water-cooled valve plate to ensure optimal thermal management during operation.

For workshop technicians performing maintenance or replacement, this part provides a direct fit for specific DAF heavy-duty vehicle engine configurations. Always verify the compatibility of the water inlet/outlet ports (M14x1,5) and the through-drive specifications before installation to ensure seamless system integration.

Technical Specifications

Cylinder BoreØ75.00
Stroke50 mm
Swept Volume442cm³
Air Inlet PortM26x1,5
Air Outlet PortM26x1,5
Number of Cylinders2
Through DriveOK
Air Unloader PortM12x1,5
Water (W) or Air (A) CooledW
Water Inlet PortM14x1,5
Water Outlet PortM14x1,5
With ESS FeatureOK
Water Cooled Valve PlateOK
Weight19,3 KG

Other OEMs

DAF

  • 1451651
  • 1310523R
  • 1310523A
  • 1310523

WABCO

  • 9115045037
  • 9115045030
  • 9115045017
  • 9115045010
  • 9115045007
  • 9115045000
  • 911.504.503.7
  • 911.504.503.0
  • 911.504.501.7
  • 911.504.501.0
  • 911.504.500.7
  • 911.504.500.0
  • 911 504 503 7
  • 911 504 503 0
  • 911 504 501 7
  • 911 504 501 0
  • 911 504 500 7
  • 911 504 500 0

Related Products

Repair Kits

Similar Products

Vehicles Used

BrandModelModel TypeEngine
DAF
DAF 95 XF FA 95 XF 530
DAF 95 XF FAS 95 XF 530
DAF 95 XF FT 95 XF 530
DAF 95 XF FTD 95 XF 380
DAF 95 XF FTD 95 XF 530
DAF 95 XF FTT 95 XF 530
DAF 95XF
DAF CF75
DAF CF85
DAF F75
DAF F95
WABCO

FAQ

What are the compatible OEM reference numbers for this part?
The compatible OEM numbers include DAF 1310523, DAF 1310523A, DAF 1310523R, DAF 1451651, WABCO 9115045007, WABCO 9115045D, WABCO 9115045N, WABCO 9123D and others.
Which vehicles is this air compressor compatible with?
This part is designed for heavy commercial vehicles such as DAF models including the CF75, CF85, F75, F95 and the 95XF series.
Does this component require water cooling?
Yes, this twin cylinder air compressor is a water-cooled (W) type featuring M-size water inlet and outlet ports for efficient thermal regulation.
What are the key technical specifications for installation?
The unit features a Ø75.0 ⊸ stroke of 5 ⊸ air inlet/outlet ports of M26x ⊸ an unloader port of M way to ensure precise fitment.
Is this part suitable for heavy-duty truck applications?
Yes, it is specifically engineered for heavy-duty vehicle air brake systems to ensure reliable pneumatic performance in professional fleets.
