1500 010 003 Twin Cylinder, Air Compressor
1500 010 003
Summary
This high-strength Twin Cylinder Air Compressor features a Ø82.00 mm cylinder bore, 56 mm stroke, and 600cm³ swept volume. Designed for heavy-duty performance, it includes a water-cooled system with Ø15 mm inlet/outlet ports and a dual-cylinder configuration. Compatible with IVECO and KNORR-BREMSE systems.
| EAN Code | 8699031077895 |
|---|
Ready to Order
Compatible OEM Codes
- KNORR-BREMSE K007304 ACX83DX
- IVECO 500329613
Description
The high-performance air compressor is a vital component for maintaining consistent pneumatic pressure within the braking system. This twin cylinder model is engineered with high-strength components to ensure long-term reliability under rigorous operational demands.
The 1500 010 003 is the OE equivalent of the IVECO 500329613 and KNORR-BREMSE ACX83DX or K007304 air compressors used in heavy commercial vehicles. With a cylinder bore of Ø82.00 mm and a stroke of 56 mm, it delivers a swept volume of 600cm³. This part is specifically designed to be compatible with IVECO and KNORR-BREMSE systems.
Maintenance technicians should note that this unit utilizes a water-cooled mechanism (W) with Ø15 mm water inlet and outlet ports to manage thermal loads effectively. The assembly includes a water-cooled valve plate and features a dual-cylinder setup with an air inlet port of Ø24 and dual air outlet ports of Ø17x2.
Regular inspection of the water cooling lines and port seals is recommended to ensure optimal system pressure and prevent overheating during heavy-duty service cycles.
The 1500 010 003 is the OE equivalent of the IVECO 500329613 and KNORR-BREMSE ACX83DX or K007304 air compressors used in heavy commercial vehicles. With a cylinder bore of Ø82.00 mm and a stroke of 56 mm, it delivers a swept volume of 600cm³. This part is specifically designed to be compatible with IVECO and KNORR-BREMSE systems.
Maintenance technicians should note that this unit utilizes a water-cooled mechanism (W) with Ø15 mm water inlet and outlet ports to manage thermal loads effectively. The assembly includes a water-cooled valve plate and features a dual-cylinder setup with an air inlet port of Ø24 and dual air outlet ports of Ø17x2.
Regular inspection of the water cooling lines and port seals is recommended to ensure optimal system pressure and prevent overheating during heavy-duty service cycles.
Technical Specifications
| Cylinder Bore | Ø82.00 |
|---|---|
| Stroke | 56 mm |
| Swept Volume | 600cm³ |
| Air Inlet Port | Ø24 |
| Air Outlet Port | Ø17x2 |
| Number of Cylinders | 2 |
| Through Drive | OK |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | Ø15 |
| Water Outlet Port | Ø15 |
| Water Cooled Valve Plate | OK |
| Weight | 17,2 KG |
Other OEMs
IVECO
- 500329613
KNORR-BREMSE
- K007304
- ACX83DX
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| IVECO | |||
| KNORR-BREMSE |
FAQ
What are the compatible OEM reference numbers for this part?
This component is compatible with IVECO 500329613, KNORR-BREMSE ACX83DX, and KNORR-BREMSE K007304.
What is the cooling method used by this air compressor?
This twin cylinder air compressor is designed as a water-cooled (W) unit, utilizing specific water inlet and outlet ports for thermal management.
Does this part fit heavy commercial vehicle systems?
Yes, this air compressor is designed specifically for heavy commercial vehicle applications within braking systems.
What are the key technical dimensions of the cylinders?
The unit features a cylinder bore of Ø82. most notably with a stroke of 56 mm and a total swept volume of 600cm³.
How can I verify compatibility with my existing system?
You can verify compatibility by checking your current system's OEM numbers against the provided list including IVECO 500329613 or KNORR-BREMSE ACX83DX.
