1200 220 001 MAN Twin Cylinder, Air Compressor
1200 220 001
Summary
High-strength air brake compressor featuring a twin cylinder design with Ø92/Ø60 bore and 490cm³ swept volume. Designed for water-cooled systems with M30x1,5 inlet and M26x1,5 outlet ports. Compatible with MAN and VOITH hardware requirements.
| EAN Code | 8699031067766 |
|---|
In Production
Compatible OEM Codes
- VOITH LP490
- MAN 51.54100-7258
Description
This high-strength air compressor is an essential component for heavy commercial vehicle pneumatic systems, ensuring reliable air pressure generation. The dual-cylinder configuration is engineered to maintain consistent performance under demanding operating conditions within the air brake system.
The 1200 220 001 is the OE equivalent of the MAN 51541007258 and VOITH LP490 air compressor used in MAN vehicles. This component features a water-cooled design with a specific cylinder bore of Ø92/Ø60 and a swept volume of 490cm³ to meet precise technical requirements. It is fully compatible with the specified MAN and VOITH hardware architectures.
Designed for professional workshop technicians, this unit includes a through-drive feature and an ESS feature for enhanced system integration. The installation requires attention to the M30x1,5 air inlet and M16x1,5 water ports to ensure optimal cooling and pressure stability. Regular inspection of the water-cooled valve plate is recommended during routine maintenance intervals to ensure long-term reliability in heavy-duty applications.
The 1200 220 001 is the OE equivalent of the MAN 51541007258 and VOITH LP490 air compressor used in MAN vehicles. This component features a water-cooled design with a specific cylinder bore of Ø92/Ø60 and a swept volume of 490cm³ to meet precise technical requirements. It is fully compatible with the specified MAN and VOITH hardware architectures.
Designed for professional workshop technicians, this unit includes a through-drive feature and an ESS feature for enhanced system integration. The installation requires attention to the M30x1,5 air inlet and M16x1,5 water ports to ensure optimal cooling and pressure stability. Regular inspection of the water-cooled valve plate is recommended during routine maintenance intervals to ensure long-term reliability in heavy-duty applications.
Technical Specifications
| Cylinder Bore | Ø92 / Ø60 |
|---|---|
| Stroke | 60 / 30 mm |
| Swept Volume | 490cm³ |
| Air Inlet Port | M30x1,5 |
| Air Outlet Port | M26x1,5 |
| Number of Cylinders | 2 |
| Through Drive | OK |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | M16x1,5 |
| Water Outlet Port | M16x1,5 |
| With ESS Feature | OK |
| Water Cooled Valve Plate | OK |
Other OEMs
MAN
- 51541007258
- 51.54100.7258
- 51.54100-7258
VOITH
- LP490
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| MAN | |||
| VOITH |
FAQ
What are the compatible OEM cross-references for this part?
This product is compatible with the following OEM numbers: 51541007258, LP490.
Is this air compressor suitable for water-cooled systems?
Yes, this twin cylinder air compressor is specifically designed for water-cooled (W) operation with dedicated water inlet and outlet ports.
Which vehicle brands or systems is this component compatible with?
This component is designed to be compatible with MAN and VOITH systems.
What are the main technical specifications of the cylinders?
The unit features a cylinder bore of Ø92/Ø60 and a stroke of 60/30 mm, providing a total swept volume of 490cm³.
Does this part include specialized features for heavy-duty use?
Yes, it includes an ESS feature and a water-cooled valve plate to ensure durability in heavy commercial vehicle braking systems.
