1100 360 002 MERCEDES BENZ Twin Cylinder, Air Compressor
1100 360 002
Summary
●Cylinder Bore: Ø92 / Ø60 ●Stroke: 60 / 30 mm ●Swept Volume: 490cm³ ●Air Inlet Port: M30x1,5 ●Air Outlet Port: M26x1,5 ●Number of Cylinders: 2 ●Through Drive: OK ●Water Cooled: W ●Water Inlet/Outlet Port: M16x1,5 ●Weight: 26.1 KG
| EAN Code | 8699031064154 |
|---|
Ready to Order
Compatible OEM Codes
- MERCEDES BENZ 457 130 79 15 457 130 63 15
- VOITH LP490
Description
This high-strength component is designed to provide reliable pneumatic pressure within the heavy commercial vehicle braking system. As a vital part of the air brake compressor assembly, it ensures consistent air delivery through its specialized twin cylinder configuration and water-cooling system.
The 1100 360 002 is the OE equivalent of the MERCEDES BENZ 4571306315 and 4571307915 and VOITH LP490 air compressors used in MERCEDES BENZ and VOITH systems. This unit features a cylinder bore of Ø92 / Ø60 with a stroke of 60 / 30 mm and a swept volume of 490cm³.
For maintenance professionals, this unit includes an ESS feature and a water-cooled valve plate to maintain optimal thermal management. The assembly utilizes an M30x1,5 air inlet port and an M26x1,5 air outlet port to ensure precise fitment within the pneumatic circuit.
Technicians should verify the water inlet and outlet ports (M16x1,5) during installation to ensure proper cooling functionality. Always consult your authorized distributor for compatibility verification with specific heavy commercial vehicle models.
The 1100 360 002 is the OE equivalent of the MERCEDES BENZ 4571306315 and 4571307915 and VOITH LP490 air compressors used in MERCEDES BENZ and VOITH systems. This unit features a cylinder bore of Ø92 / Ø60 with a stroke of 60 / 30 mm and a swept volume of 490cm³.
For maintenance professionals, this unit includes an ESS feature and a water-cooled valve plate to maintain optimal thermal management. The assembly utilizes an M30x1,5 air inlet port and an M26x1,5 air outlet port to ensure precise fitment within the pneumatic circuit.
Technicians should verify the water inlet and outlet ports (M16x1,5) during installation to ensure proper cooling functionality. Always consult your authorized distributor for compatibility verification with specific heavy commercial vehicle models.
Technical Specifications
| Cylinder Bore | Ø92 / Ø60 |
|---|---|
| Stroke | 60 / 30 mm |
| Swept Volume | 490cm³ |
| Air Inlet Port | M30x1,5 |
| Air Outlet Port | M26x1,5 |
| Number of Cylinders | 2 |
| Through Drive | OK |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | M16x1,5 |
| Water Outlet Port | M16x1,5 |
| With ESS Feature | OK |
| Water Cooled Valve Plate | OK |
| Weight | 26,1 KG |
Other OEMs
MERCEDES BENZ
- A4571307915
- A4571306315
- 4571307915
- 4571306315
- 457.130.7915
- 457.130.79.15
- 457.130.6315
- 457.130.63.15
- 457 130 7915
- 457 130 6315
- 457 130 79 15
- 457 130 63 15
VOITH
- LP490
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| MERCEDES BENZ | |||
| VOITH |
FAQ
What are the compatible OEM reference numbers for this part?
This product is compatible with the following OEM references: 4571306315, 4571307915, and LP490.
Is this air compressor suitable for water-cooled systems?
Yes, this twin cylinder air compressor is specifically designed for water-cooled (W) applications with M16x1,5 ports.
Which vehicle brands is this component compatible with?
This part is engineered to be compatible with systems from MERCEDES BENZ and VOITH.
What are the main technical specifications of this unit?
The unit features a Ø92 / Ø60 cylinder bore, a stroke of 60 / 30 mm, and a total swept volume of 490cm³.
Does this part include the ESS feature?
Yes, this air compressor is equipped with the ESS feature as specified in the technical documentation.
