1100 080 001 MERCEDES BENZ Single Cylinder, Air Compressor

This high-strength single cylinder air compressor is engineered to provide reliable air pressure within the pneumatic braking system of heavy commercial vehicles. Designed for durability, this component ensures consistent performance under demanding operating conditions for workshop technicians and fleet managers.

The 1100 080 001 is the OE equivalent of the MERCEDES BENZ 4471302015 air compressor used in MERCEDES BENZ vehicles. This specific unit features a cylinder bore of Ø100.00 and a stroke of 48 mm, with a swept volume of 377cm³. It is specifically designed for water-cooled systems to maintain optimal temperature regulation during operation.

Technical specifications include an air inlet and outlet port of M26x1,5 and water ports of M14x1,5. The through-drive design and water-cooled valve plate ensure structural integrity and long-term service life in heavy-duty applications. It is essential to verify the exact port dimensions and cooling requirements before installation to ensure seamless integration with the existing vehicle system.

Regular inspection of the air compressor and its connection points is recommended to prevent pressure loss or system failures. Maintaining the water cooling flow and checking for leaks at the M26x1,5 ports will help extend the component's operational life in commercial vehicle fleets.
