0106 004 DAF Sensor Ring, ABS Sensor
0106 004
The 0106 004 Sensor Ring is a precision-engineered component for brake systems. It features an inside diameter of 169/179 mm, an outside diameter of 183/212 mm, a height of 15,5/17,5 mm, and includes 100 holes for secure mounting.
| EAN Code | 8699031062518 |
|---|
Compatible OEM Codes
- DAF 1805824 1657638
Description
The 0106 004 sensor ring is a critical component within the brake system, specifically designed to provide precise positioning for ABS sensors. Engineered with high-strength components, this part ensures reliable signal transmission and durability under demanding heavy commercial vehicle operating conditions.
This sensor ring is the OE-equivalent of the DAF 1657638 and 1805824 parts used in DAF heavy vehicles. It maintains exact technical specifications to ensure seamless integration into the vehicle's braking architecture. The part is specifically engineered to match the requirements of high-performance electronic braking subsystems.
For workshop technicians, this component offers a straightforward installation process due to its precise dimensions and 100-hole mounting configuration. Regular inspection of the sensor ring and surrounding components during scheduled maintenance is recommended to ensure the continued accuracy of the ABS system and prevent electronic signaling errors.
Technical Specifications
| Inside Diameter (d) | 169/179 mm |
|---|---|
| Outside Diameter (D) | 183/212 mm |
| Height | 15,5/17,5 mm |
| Number Of Holes | 100 |
Other OEMs
DAF
- 1805824
- 1657638
Vehicles Used
| Brand | Model | Engine |
|---|---|---|
| DAF |
