301.07.0158 Volvo Pressure Limiting Valve Equivalent

What does a pressure limiting valve do?

This pressure limiting valve plays a critical role in maintaining optimal air pressure within the pneumatic braking and suspension systems of heavy commercial vehicles. By utilizing a precise piston-and-spring mechanism, it regulates air flow to ensure system stability and safety during operation.

Vehicle and engine compatibility

This component is specifically engineered for compatibility with various Volvo models, including the F10, F12, FL10, FL12, N10, N12, NL10, NL12, B10B, B10M, and B12 series. It is also fitted to other heavy commercial vehicles such as Scania, MAN, and Mercedes-Benz trucks. The valve is designed to function effectively with engines including TD100, TD120, D10A, and D12A.

Installation and maintenance

For proper installation, ensure that the M22x1.5 ports are clean and the connections are tightened to manufacturer specifications to prevent leaks. Technicians should check the non-return function during routine maintenance to ensure the valve is effectively managing the 7-0.3 Bar pressure threshold.

System reliability

Regular inspection of the pneumatic lines connected to this valve can help prevent premature wear of the internal components and maintain consistent braking performance across the vehicle fleet.

OE cross-reference

301.07.0158 (Pressure Limiting Valve) is the equivalent of the Alexander Dennis, Iveco, Kässbohrer, Liebherr, Renault Trucks, Scania, VDL, Volvo and WABCO OE numbers. This part directly replaces Alexander Dennis OE number 661787. It also replaces Iveco OE numbers 8169973, 8169974, Kässbohrer OE number 8025068000, Liebherr OE number 511233405, Renault Trucks OE number 5000590248, Scania OE number 2089947, VDL OE number 41155663, Volvo OE number 3181897 and WABCO OE number 4341001300.
