301.07.0051 Pressure Limiting Valve
1005 Visualized

301.07.0051 DAF Pressure Limiting Valve

301.07.0051

Summary

●Port 1: M16x1,5 ●Port 2: M16x1,5 ●Inlet Pressure: 11 BAR ●Adjustment Range: 4,0 …..8,0 BAR ●Outlet Pressure: 6,7 BAR ± 0,2 BAR ●Security Pressure: 9,2 BAR

EAN Code8683457011564
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Compatible OEM Codes

  • WABCO 475 015 036 0
  • VOLVO 21410698
  • IVECO 98434798
  • DAF 1518118

Description

The high-strength components of this pressure limiting valve ensure precise regulation within the pneumatic braking system. Designed for heavy commercial vehicle applications, this part maintains consistent pressure levels to support safe and reliable operation under demanding driving conditions.

301.07.0051 is the OE-equivalent of the DAF 1518118, IVECO 98434798, VOLVO 21410698, and WABCO 475 015 036 0 systems used in DAF, IVECO, IRISBUS, PACCAR, and VOLVO vehicles. This component is engineered to meet strict technical standards for seamless integration with original braking hardware.

Workshop technicians can rely on the precise adjustment range of 4,0 to 8,0 BAR to maintain optimal system stability. The M16x1,5 port specifications ensure a secure fit during installation. Regular maintenance checks of the outlet pressure and security thresholds are recommended to ensure the longevity of the braking system components.

Technical Specifications

Port 1M16x1,5
Port 2M16x1,5
Inlet Pressure11 BAR
Adjustment Range4,0 …..8,0 BAR
Outlet Pressure6,7 BAR ± 0,2 BAR
Safety Pressure9,2 BAR

Other OEMs

DAF

  • 1518118

IVECO

  • 98434798

VOLVO

  • 21410698

WABCO

  • 4750150360
  • 475 015 036 0

Vehicles Used

BrandModelEngine
DAF
IRISBUS
IVECO
PACCAR
VOLVO
WABCO

FAQ

Which vehicle brands is this valve compatible with?
This pressure limiting valve is compatible with DAF, IVECO, IRISBUS, PACCAR, and VOLVO heavy commercial vehicles.
What are the exact OEM equivalent numbers for this part?
The OE equivalents include DAF 1518118, IVECO 98434798, VOLVO 21410698, and WABCO 475 015 036 0.
What are the technical port specifications?
The unit features two M16x1,5 ports for reliable connection within the brake system.
What is the adjustment range for the outlet pressure?
The adjustment range is between 4,0 and 8,0 BAR, with a standard outlet pressure of 6,7 BAR ± 0,2 BAR.
Is this part suitable for heavy-duty truck braking systems?
Yes, it is designed with high-strength components specifically for heavy commercial vehicle braking systems.
