8113405 SP2 Volvo D16 Compatible Twin Cylinder Compressor
1300 090 004
Summary
This heavy-duty twin cylinder compressor is designed for Volvo TAMD162 D16 engines. It features a Ø88.00 mm cylinder bore, 50 mm stroke, and a 608cm³ swept volume. This water-cooled unit ensures reliable air production for heavy commercial vehicle braking systems. Equivalent to OE Volvo 8113405SP2.
| EAN Code | 8699031049892 |
|---|
Ready to Order
Compatible OEM Codes
-
VOLVO
- 85000066 SP2
- 8113405 SP2
- 3173001 SP2
- 20429343 SP2
-
KNORR-BREMSE
- LP4985 SP2
Description
What does a twin cylinder compressor do?
This twin cylinder compressor is an engine-driven unit in the air brake system of heavy commercial vehicles that generates compressed air using two piston-cylinder assemblies.Compatibility with Volvo engines
Designed specifically for Volvo TAMD162 engines with D16 configurations, this component provides high-capacity air delivery required for heavy-duty braking systems. The unit features a Ø88.00 mm cylinder bore, a 50 mm stroke, and a 608cm³ swept volume to ensure efficient pressure buildup. This specific model is water-cooled and includes an ESS feature to maintain optimal operating temperatures during intensive service.Technical specifications and cooling
The assembly is engineered with high-strength components to withstand the rigors of heavy commercial vehicle operation. It includes an M26x1,5 air outlet port and an M22x1,5 air unloader port, alongside M16x1,5 water inlet and outlet ports. The through-drive configuration ensures precise synchronization with the engine crankshaft.Installation and maintenance
Maintenance technicians should verify that all port connections and water cooling lines are secured to prevent pressure drops or thermal issues. When replacing the unit, ensure the mounting flange and drive gear match the original specifications to maintain system integrity.OE cross-reference
1300 090 004 (Twin Cylinder Compressor) is the equivalent of the Volvo OE number. This part directly replaces Volvo OE number 8113405SP2.Technical Specifications
| Cylinder Bore | Ø88.00 |
|---|---|
| Stroke | 50 mm |
| Swept Volume | 608cm³ |
| Air Inlet Port | Ø29 |
| Air Outlet Port | M26x1,5 |
| Number of Cylinders | 2 |
| Through Drive | OK |
| Air Unloader Port | M22x1,5 |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | M16x1,5 |
| Water Outlet Port | M16x1,5 |
| With ESS Feature | OK |
| Water Cooled Valve Plate | OK |
Other OEMs
KNORR-BREMSE
- LP4985 SP2
VOLVO
- 85000066 SP2
- 8113405 SP2
- 3173001 SP2
- 20429343 SP2
Related Products
Repair Kits
Similar Products
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| KNORR-BREMSE | |||
| VOLVO | |||
| VOLVO | F16 | TD162 | |
| VOLVO | FH16 | D16A | |
| VOLVO | FH16 | D16B | |
| VOLVO | L330C / L330D / L330E | D16 | |
| VOLVO | TAD1630 | D16 | |
| VOLVO | TAMD162 | D16 |
FAQ
What is the function of this twin cylinder compressor?
It uses two piston-cylinder assemblies to generate compressed air for the vehicle's pneumatic braking system, providing higher output than single-cylinder units.
Which engines is this compressor compatible with?
This unit is specifically designed for use in Volvo TAMD162 engines with the D16 configuration.
How does the cooling system work on this unit?
This is a water-cooled unit that utilizes M16x1,5 inlet and outlet ports to manage operating temperatures effectively.
What are the key technical dimensions?
The compressor features a Ø88.00 mm bore, a 50 mm stroke, and a total swept volume of 608cm³.
What are the OE reference numbers of this part?
1300 090 004 directly replaces Volvo OE number 8113405SP2.
