301.07.0069 Pressure Limiting Valve Compatible
301.07.0069
The 301.07.0069 Pressure Limiting Valve is a precision-engineered component designed for heavy commercial vehicle brake systems. It features Port 1 (M22x1,5) and Port 2 (M22x1,5) configurations, an inlet pressure of 7,5 BAR, an adjustment range of 5,8 – 10,8 BAR, and a fixed outlet pressure of 6 BAR.
| EAN Code | 8683457011748 |
|---|
Compatible OEM Codes
- SCHMITZ CARGOBULL 50608 050608
- WABCO 475 010 305 0
- VOLVO 527331288000
- VDL 41156051
- SCHWARZMULLER 35230
- SCANIA 2090274
- MERCEDES BENZ 662 320 17 58
- LIEBHERR 502662708
- LANGENDORF 1111694
- KÖGEL 335702
- KASSBOHRER 21622300003
- FORD 3C46 2L129 A2A
- FAUN 99707005414
- DAF 1518931
- DAEWOO 3425600060
Description
The technical function of this pressure limiting valve is to regulate air pressure within the brake system, ensuring stable pneumatic operation under varying load conditions. Designed for heavy-duty grade materials, this component maintains consistent pressure regulation through its specific adjustment range of 5,8 to 10,8 BAR.
301.07.0069 is the OE-equivalent of the WABCO 475 010 305 0 pressure limiting valve used in Mercedes Benz, Scania, DAF, and Volvo heavy commercial vehicles. It is also fully compatible with systems from DAEWOO, FAUN, FORD, KASSBOHRER, KÖGEL, LANGENDORF, LIEBHERR, SCHMITZ CARGOBULL, SCHWARZMULLER, VDL, and WABCO.
Workshop technicians should ensure that the M22x1,5 ports are correctly seated to prevent pneumatic leaks. Proper installation requires checking the inlet pressure against the 7,5 BAR specification to maintain the intended 6 BAR outlet pressure. Regular maintenance of the brake system components ensures long-term reliability of the pneumatic circuit in truck and bus applications.
Technical Specifications
| Port 1 | M22x1,5 |
|---|---|
| Port 2 | M22x1,5 |
| Inlet Pressure | 7,5 BAR |
| Adjustment Range | 5,8 …..10,8 BAR |
| Outlet Pressure | 6 BAR |
Other OEMs
DAEWOO
- 3425600060
DAF
- 1518931
FAUN
- 99707005414
FORD
- 3C462L129A2A
- 3C46 2L129 A2A
KASSBOHRER
- 21622300003
KÖGEL
- 335702
LANGENDORF
- 1111694
LIEBHERR
- 502662708
MERCEDES BENZ
- A6623201758
- 6623201758
- 662 320 17 58
SCANIA
- 2090274
SCHMITZ CARGOBULL
- 50608
- 050608
SCHWARZMULLER
- 35230
VDL
- 41156051
VOLVO
- 527331288000
WABCO
- 4750103050
- 475 010 305 0
Vehicles Used
| Brand | Model | Engine |
|---|---|---|
| DAEWOO | ||
| DAF | ||
| FAUN | ||
| FORD | ||
| GOLDHOFER | ||
| KASSBOHRER | ||
| KÖGEL | ||
| LANGENDORF | ||
| LIEBHERR | ||
| MERCEDES BENZ | ||
| SCANIA | ||
| SCHMITZ CARGOBULL | ||
| SCHWARZMULLER | ||
| TIRSAN | ||
| VDL | ||
| VOLVO | ||
| WABCO |
