301.07.0044 Pressure Limiting Valve
2397 Visualized

301.07.0044 Pressure Limiting Valve Compatible

301.07.0044

Summary

●Port 1: M16x1,5 ●Port 2: M16x1,5 ●Inlet Pressure: 10 BAR ●Adjustment Range: 4,0 – 8,0 BAR ●Outlet Pressure: 4,0 BAR + 0,2 BAR ●Security Pressure: 6,3 BAR

EAN Code8683457011496
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Compatible OEM Codes

  • MAN 99.11236-0088 88.52101-6009
  • WABCO 475 015 015 0
  • VOLVO 21410696
  • SCANIA 2090286
  • RENAULT TRUCKS 5010559251
  • MERCEDES BENZ 002 431 54 06
  • IVECO 500346852

Description

This high-strength component serves a critical function within the brake system to regulate air pressure accurately. Designed for heavy-duty applications, the pressure limiting valve ensures stable pneumatic regulation through its precise adjustment range and robust construction.

301.07.0044 is the OE equivalent of the IVECO 500346852 pressure limiting valve used in IVECO, MAN, MERCEDES BENZ, RENAULT TRUCKS, SCANIA, VOLVO, and WABCO systems. This part is engineered to meet strict technical specifications for heavy commercial vehicles including compatibility with MAN NEOPLAN models.

Workshop technicians should ensure the M16x1,5 ports are clear and correctly seated during installation to maintain the specified 4,0 to 8,0 BAR adjustment range. Regular inspections of the pneumatic lines and connection points are recommended to ensure optimal braking performance and system integrity within the heavy commercial vehicle chassis.

Technical Specifications

Port 1M16x1,5
Port 2M16x1,5
Inlet Pressure10 BAR
Adjustment Range4,0 …..8,0 BAR
Outlet Pressure4,0 BAR + 0,2 BAR
Safety Pressure6,3 BAR

Other OEMs

IVECO

  • 500346852

MAN

  • 99112360088
  • 88521016009
  • 99.11236-0088
  • 88.52101-6009

MERCEDES BENZ

  • A0024315406
  • 002 431 54 06

RENAULT TRUCKS

  • 5010559251

SCANIA

  • 2090286

VOLVO

  • 21410696

WABCO

  • 4750150150
  • 475 015 015 0

Vehicles Used

BrandModelEngine
EVOBUS
IRISBUS
IVECO
MAN
MAN NEOPLAN
MERCEDES BENZ
NEOPLAN
RENAULT TRUCKS
SCANIA
SCHWARZMULLER
STEYR
VOLVO
WABCO

FAQ

What are the technical port specifications for this valve?
The valve features two M16x1,5 ports (Port 1 and Port 2) designed for secure pneumatic connections in heavy commercial vehicle braking systems.
Which OEM numbers is this part compatible with?
It is compatible with IVECO 500346852, MAN 88.52101-6009 and 99.11236-0088, MERCEDES BENZ 002 431 54 06, RENAULT TRUCKS 5010559251, SCANIA 2090286, VOLVO 21410696, and WABCO 475 own 015 015 0.
What is the pressure adjustment range for this component?
The device operates with an inlet pressure of up to 10 BAR and features an adjustable range between 4, hands to 8, hands BAR to regulate output effectively.
Is this part suitable for heavy commercial vehicles?
Yes, it is specifically designed for heavy commercial vehicle applications including trucks and buses from brands like MAN, IVECO, and SCANIA.
Does it support high-pressure stability?
Yes, the valve provides a security pressure of up to 6,3 BAR to ensure stable operation within the pneumatic brake system.
