301.07.0024 IVECO Quick Release Valve
301.07.0024
Summary
This high-strength Quick Release Valve is designed for heavy commercial vehicle brake systems. Featuring Port 1: M22x1,5, Port 2: M16x1,5 (x2), and Port 3: M16x1,5, it operates at a maximum pressure of 10 BAR. Compatible with IVECO, RENAULT TRUCKS, and VOLVO systems.
| EAN Code | 8683457009059 |
|---|
Ready to Order
Compatible OEM Codes
- VOLVO 8123281 8120601 6883355 3173152 1581929 1135002
- WABCO 973 500 047 0
- RENAULT TRUCKS 5000785730
- IVECO 61582103
Description
The VADEN ORIGINAL 301.07.0024 is a precision-engineered component designed for reliable performance within the brake system of heavy commercial vehicles. This quick release valve ensures optimal pneumatic control and durability under rigorous operational conditions. It is built with high-strength components to maintain consistent pressure regulation throughout its service life.
The 301.07.0024 is the OE equivalent of the IVECO 61582103 used in IVECO, RENAULT TRUCKS, and VOLVO (including F10, F12, FL10, FL12, N10, N12, NL10, NL12, B10B, B10M, B12 models) and WABCO (9735000470) systems. This part ensures seamless integration with the vehicle's pneumatic architecture.
Designed for professional workshop technicians and fleet managers, this component features specialized port dimensions: Port 1 is M22x1,5; Port 2 includes two M16x1,5 ports; and Port 3 is M16x1,5. It is engineered to handle a maximum operating pressure of up to 10 BAR.
Regular inspection of the pneumatic connections and valve seating is recommended to ensure optimal braking system response and prevent air leaks in heavy-duty applications.
The 301.07.0024 is the OE equivalent of the IVECO 61582103 used in IVECO, RENAULT TRUCKS, and VOLVO (including F10, F12, FL10, FL12, N10, N12, NL10, NL12, B10B, B10M, B12 models) and WABCO (9735000470) systems. This part ensures seamless integration with the vehicle's pneumatic architecture.
Designed for professional workshop technicians and fleet managers, this component features specialized port dimensions: Port 1 is M22x1,5; Port 2 includes two M16x1,5 ports; and Port 3 is M16x1,5. It is engineered to handle a maximum operating pressure of up to 10 BAR.
Regular inspection of the pneumatic connections and valve seating is recommended to ensure optimal braking system response and prevent air leaks in heavy-duty applications.
Technical Specifications
| Port 1 | M22x1,5 |
|---|---|
| Port 2 | M16x1,5 (x2) |
| Port 3 | M16x1,5 |
| Pressure | MAX 10 BAR |
Other OEMs
IVECO
- 61582103
RENAULT TRUCKS
- 5000785730
VOLVO
- 8123281
- 8120601
- 6883355
- 3173152
- 1581929
- 1135002
WABCO
- 9735000470
- 973 500 047 0
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| IVECO | |||
| RENAULT TRUCKS | |||
| VOLVO | |||
| VOLVO | B10B | D10A | |
| VOLVO | B10M | D10A | |
| VOLVO | B10M | TD100 | |
| VOLVO | B12 | D12A | |
| VOLVO | B12 | TD120 | |
| VOLVO | F10 | TD100 | |
| VOLVO | F10 | TD101 | |
| VOLVO | F10 | TD102 | |
| VOLVO | F12 | TD120 | |
| VOLVO | F12 | TD121 | |
| VOLVO | F12 | TD122 | |
| VOLVO | F7 | TD70 | |
| VOLVO | F7 | TD71 | |
| VOLVO | FL10 | D10A | |
| VOLVO | FL10 | TD102 | |
| VOLVO | FL10 | TD103 | |
| VOLVO | FL12 | TD122 | |
| VOLVO | FL12 | TD123 | |
| VOLVO | N10 | TD100 | |
| VOLVO | N10 | TD101 | |
| VOLVO | N12 | TD120 | |
| VOLVO | N12 | TD122 | |
| VOLVO | NL10 | D10A | |
| VOLVO | NL12 | D12A | |
| WABCO |
FAQ
What are the technical specifications of this valve?
The valve features Port 1 (M22x1,5), two Port 2 connections (M16x1,5), and one Port 3 connection (M16x1,5), with a maximum pressure rating of 10 BAR.
Which vehicle brands are compatible with this part?
This component is compatible with IVECO, RENAULT TRUCKS, VOLVO (including various F-series and B-series models), and WABCO systems.
Can I use this as an OE replacement for Volvo or Iveco?
Yes, it serves as an OE equivalent for IVECO 61582103 and various Volvo references such as 1135002, 8123281, and 8120601.
Is this part suitable for heavy-duty truck braking systems?
Yes, it is specifically designed for the pneumatic brake systems of heavy commercial vehicles including trucks and buses.
What are the compatible OEM reference numbers?
The compatible OEM codes include IVECO 61582103, RENAULT TRUCKS 5000785730, VOLVO 1135002, 8123281, 8120601, and WABCO 9735000470.
