301.07.0019 Quick Release Valve
7107 Visualized

301.07.0019 Quick Release Valve — DAF

301.07.0019

Summary

●Port 1: G 1/2" PTF ●Port 2: G 3/8" NPTF (x2) ●Port 3: G 3/8" NPTF ●Pressure: MAX 10 BAR. This high-strength component is designed for precise pneumatic control in heavy commercial vehicle brake systems.

EAN Code8683457009004
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Description

The high-strength component designed for the brake system ensures reliable pressure regulation within pneumatic circuits. This Quick Release Valve is engineered to handle heavy-duty duty cycles, providing stable performance in demanding heavy commercial vehicle environments.

301.07.0019 is the OE-equivalent Quick Release Valve used in DAF (1504913, 1518272), SCANIA (186568, 193567), VOLVO (10898797, 1584448, 328773, 6864241), RENAULT TRUCKS (3743490, 71802875, 71803469), and IVECO (3344855R1) systems. It also serves as a compatible replacement for various Ford, Foden, and Leyland specifications.

For workshop technicians, this part offers straightforward installation with specific port requirements: Port 1 features G 1/2" PTF, while Port 2 includes two G 3/8" NPTF connections and Port 3 provides a single G 3/8" NPTF connection. It is essential to verify the maximum operating pressure of 10 BAR during assembly to ensure optimal system safety and prevent pneumatic leaks.

Technical Specifications

Port 1G 1/2" PTF
Port 2G 3/8" NPTF (x2)
Port 3G 3/8" NPTF
PressureMAX 10 BAR

Other OEMs

DAF

  • 1504913
  • 1518272

ERF

  • 18686
  • 85396

FODEN

  • 7235003
  • FG11857
  • Y00143405

FORD

  • 73DB-2A095-DA
  • 73RB-2AO95-AA
  • 82RB-2A095-A1A
  • 73DB2A095DA
  • 73RB2AO95AA
  • 82RB2A095A1A

FRUEHAUF

  • CF350089

IVECO

  • 3344855R1

LEYLAND

  • 10898550
  • 13H3968
  • FBU3341

RENAULT TRUCKS

  • 37434900
  • 71802875
  • 71803469

SCANIA

  • 186568
  • 1935671

VAN HOOL

  • 11173539

VOLVO

  • 10898797
  • 1584448
  • 328773
  • 6864241

WABCO

  • 973 500 014 0
  • 9735000140

Vehicles Used

BrandModelEngine
ALEXANDER DENNIS
DAF
ERF
FODEN
FORD
FRUEHAUF
IVECO
KENWORTH
LEYLAND
MERITOR
PACCAR
PETERBILT
RENAULT TRUCKS
SCANIA
VAN HOOL
VOLVO
WABCO

FAQ

Which vehicle brands are compatible with this Quick Release Valve?
This part is compatible with DAF (1504913, 1518272), SCANIA (186568, 193567), VOLVO (10898797, 6864241), IVECO (3344855R1), and RENAULT TRUCKS (3743490). It also fits FORD and FODEN models.
What are the technical port specifications for this part?
The unit features Port 1: G 1/2" PTF, Port 2: G 3/8" NPTF (x2), and Port 3: G 3/8" NPTF. It is designed for a maximum pressure of up to 10 BAR.
Can this be used as an OE equivalent for WABCO systems?
Yes, it is a high-quality compatible option for WABCO system code 973 500 014 0 and other compatible pneumatic systems.
Is this product suitable for heavy commercial vehicles?
Yes, it is specifically engineered for the heavy commercial vehicle sector, including trucks and buses from brands like DAF, Volvo, and Scania.
Does this part meet the required pressure standards?
The component is built to maintain stability in systems with a maximum operating pressure of up to 10 BAR.
