301.07.0013 Quick Release Valve, Brake System
4257 Views Updated

301.07.0013 Compatible Quick Release Valve

301.07.0013

Summary

This high-strength quick release valve features M22x1.5 ports (including two M22x1.5 outlets) and a maximum operating pressure of 10 BAR. It is designed to optimize pneumatic brake response in heavy-duty vehicles, ensuring efficient air venting for Scania, DAF, and Iveco trucks. Equivalent to OE DAF 1506661, Iveco 222723 and Leyland 830786.

Product identifiers
EAN Code8683457008946
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Compatible OEM Codes

  • SCANIA
    • 2205624
    • 1738491
  • WABCO
    • 473 501 000 0
  • VAN HOOL
    • 637211650
  • RENAULT TRUCKS
    • 5000440820
  • NOOTEBOOM
    • 3503837
  • LEYLAND
    • 830786
  • IVECO
    • 222723
  • DAF
    • 1506661

Description

What does a quick release valve do?

This quick release valve serves as a critical component within the pneumatic brake circuit of heavy commercial vehicles. By rapidly venting compressed air from the brake chambers upon pedal release, it minimizes response lag and ensures the immediate disengagement of brake linings. This component is manufactured using high-strength components to withstand the rigorous demands of heavy-duty braking cycles.

Vehicle and system compatibility

This valve is designed for compatibility with various heavy commercial vehicles including DAF, Iveco, Leyland, Nooteboom, Renault Trucks, Scania, Van Hool, and also fitted to other major makes. It is specifically engineered to be compatible with WABCO systems.

Installation and maintenance

Technicians should verify that the port configuration—specifically the M22x1.5 connections—matches the existing pneumatic lines before installation. Proper mounting near the rear axle brake chambers ensures optimal performance and helps preserve the longevity of the braking system components.

Maintenance guidance

Regular inspection of the valve body and connection points can help prevent air leaks and maintain consistent braking performance across the fleet.

OE cross-reference

301.07.0013 (Quick Release Valve) is the equivalent of the DAF, Iveco, Leyland, Nooteboom, Renault Trucks, Scania, Van Hool and WABCO OE numbers. This part directly replaces DAF OE number 1506661. It also replaces Iveco OE number 222723, Leyland OE number 830786, Nooteboom OE number 3503837, Renault Trucks OE number 5000440820, Scania OE numbers 1738491, 2205624, Van Hool OE number 637211650 and WABCO OE number 4735010000.

Technical Specifications

Technical Specifications
Port 1M22x1,5
Port 2M22x1,5 (x2)
Port 3M22x1,5
PressureMAX 10 BAR

Other OEMs

DAF

  • 1506661

IVECO

  • 222723

LEYLAND

  • 830786

NOOTEBOOM

  • 3503837

RENAULT TRUCKS

  • 5000440820

SCANIA

  • 2205624
  • 1738491

VAN HOOL

  • 637211650

WABCO

  • 4735010000
  • 473 501 000 0

Compatible Vehicles

Compatible Vehicles
BrandModelModel TypeEngine
DAF
IVECO
LEYLAND
NOOTEBOOM
RENAULT TRUCKS
SCANIA
VAN HOOL
WABCO

FAQ

What is the function of this quick release valve?
It rapidly vents compressed air from the brake chambers as soon as the pedal is released, reducing braking lag and improving safety.
Which vehicle makes are compatible with this part?
This valve is compatible with DAF, Iveco, Leyland, Nooteboom, Renault Trucks, Scania, and Van Hool vehicles.
Is this component compatible with WABCO systems?
Yes, this valve is designed to be compatible with WABCO systems used in heavy commercial vehicle braking circuits.
What are the technical connection specifications?
The unit features M22x1.5 port connections and is rated for a maximum operating pressure of 10 BAR.
What are the OE reference numbers of this part?
301.07.0013 directly replaces DAF OE number 1506661. It also replaces Iveco OE number 222723, Leyland OE number 830786, Nooteboom OE number 3503837, Renault Trucks OE number 5000440820, Scania OE numbers 1738491, 2205624, Van Hool OE number 637211650 and WABCO OE number 4735010000.
