303.02.0044 Compatible 4-Circuit Protection Valve
303.02.0044
Summary
This 4-circuit protection valve is engineered for heavy commercial vehicle brake systems. It features M22x1.5 and M16x1.5 ports, operating at 12 BAR, ensuring precise pressure management and reliability in demanding environments. Equivalent to OE Knorr-Bremse AE4616.
| EAN Code | 8683457005235 |
|---|
Ready to Order
Compatible OEM Codes
-
KNORR-BREMSE
- II36150
- AE 4616
Description
What does a protection valve do?
This protection valve plays a critical role in the pneumatic brake system by dividing the air supply into multiple independent circuits. By isolating different braking sections, it ensures that a leak in one area does not lead to a total loss of braking capability, maintaining essential safety standards for heavy commercial vehicles.System compatibility and design
This component is designed to function within complex pneumatic systems, offering high-strength construction for durability. It is compatible with Knorr-Bremse systems and is engineered to manage pressure fluctuations effectively during heavy-duty operation.Technical specifications and installation
Technical specifications include an operating pressure of 12 BAR and a maximum pressure rating of 20 BAR. The valve features a primary M22x1.5 port alongside M16x1.5 ports for the various circuit outlets, providing precise control through specific opening and closing pressure thresholds.Maintenance and selection
When replacing this unit, technicians should verify all port connections and ensure the pressure settings align with the vehicle's original specifications to maintain optimal braking performance. Consult your authorized distributor.OE cross-reference
303.02.0044 (4-circuit protection valve) is the equivalent of the Knorr-Bremse OE numbers. This part directly replaces Knorr-Bremse OE numbers AE4616, II36150.Technical Specifications
