302.01.0001 Foot Brake Valve — MERCEDES BENZ
302.01.0001
The VADEN ORIGINAL 302.01.0001 is a high-strength component designed for heavy commercial vehicle brake systems. It features four M16x1,5 ports (Ports 11, 12, 21, and 22) and operates with a maximum pressure of 10 BAR and 0,3 BAR dominance. This part is engineered for compatibility with major systems including MERCEDES BENZ, SCANIA, and MAN.
| EAN Code | 8699031064222 |
|---|
Description
The heavy-duty foot brake valve is a critical component within the pneumatic braking system of heavy commercial vehicles, ensuring precise control and responsiveness during deceleration. This high-strength component is engineered to maintain optimal pressure regulation under rigorous operational demands, providing essential stability to the braking circuit.
302.01.0001 is the OE-equivalent foot brake valve used in MERCEDES BENZ ( 001 431 83 05 , 001 431 89 05 , 001 431 91 05 , 001 431 99 05 , 002 431 27 05 , 345 431 71 05 ), SCANIA ( 1314047 , 1347911 , 354611 , 571122 , 571123 , 571133 ), MAN ( 85.50001-1690 , 85.50001-1955 , 85.50001-1956 , 85.50001-3458 , 99.10036-0073 ), and WABCO ( 461 315 008 0 ). This part also supports compatibility with DAF ( 151806) and IVECO ( 4783981 , 48410 lack ) systems.
Designed for professional workshop-level installation, the valve utilizes four M16x1,5 ports (Port numbers: 12, 21, 22, and 11) to ensure a secure and leak-free connection within the pneumatic line. Workshop technicians should verify all port sizes and ensure the system pressure does not exceed the maximum rating of 10 BAR to maintain long-term component integrity and safety during vehicle service intervals.
Technical Specifications
| Port 12 | M16x1,5 |
|---|---|
| Port 21 | M16x1,5 |
| Port 22 | M16x1,5 |
| Port 11 | M16x1,5 |
| Pressure | MAX 10 BAR |
| Dominance | 0,3 BAR |
Other OEMs
DAEWOO
- Z442145010087
DAF
- 1518060
FAUN
- 1617213
- 99708458694
FORD
- 1C442 A270A 1A
- 1C442A270A1A
IVECO
- 04783981
- 4783981
- 4841006
LEYLAND
- BBU6441
LIEBHERR
- 5029929
- 502992908
- 502992977
- 5029929R
MAN
- 85.50001-1690
- 85.50001-1955
- 85.50001-1956
- 85.50001-3458
- 99.10036-0073
- 85.50001-4354
- 85.50001.4354
- 85500011690
- 85500011955
- 85500011956
- 85500013458
- 85500014354
- 99.10036.0073
- 99100360073
MERCEDES BENZ
- 001 431 83 05
- 001 431 89 05
- 001 431 91 05
- 001 431 99 05
- 002 431 27 05
- 345 431 71 05
- 001 431 8305
- 001 431 8905
- 001 431 9105
- 001 431 9905
- 001.431.83.05
- 001.431.8305
- 001.431.89.05
- 001.431.8905
- 001.431.91.05
- 001.431.9105
- 001.431.99.05
- 001.431.9905
- 0014318305
- 0014318905
- 0014319105
- 0014319905
- 002 431 2705
- 002.431.27.05
- 002.431.2705
- 0024312705
- A0014318305
- A0014318905
- A0014319105
- A0014319905
- A0024312705
- A3454317105
ProVia
- PRO 315 008 0
RENAULT TRUCKS
- 5021170165
SCANIA
- 1314047
- 1347911
- 354611
- 571122
- 571123
- 571133
STEYR
- 79200360035
- 79200360036
VOLKSWAGEN TRUCK
- T00607357B
VOLVO
- 1589620
- 6996123
WABCO
- 461 315 008 0
- 461.315.008.0
- 4613150080
