301.07.0149 Pressure Limiting Valve Compatible
301.07.0149
●Port 1: M22x1.5 ●Port 2: M22x1.5 ●Pressure: 4.8-0.3 Bar ●Return: OK
| EAN Code | 8683457046481 |
|---|
Compatible OEM Codes
- VOLVO 3181898 1932736
- WABCO 434 100 082 0
- RENAULT TRUCKS 7403181898
- MERCEDES BENZ 004 429 81 44
- MAN 81.52110-6101
- DAF 1236573
Description
The heavy-duty pressure limiting valve is a critical component within the pneumatic brake system, ensuring precise pressure regulation and stability. Designed with high-strength components, this part maintains optimal performance under rigorous operational conditions to ensure vehicle safety and system integrity.
301.07.0149 is the OE-equivalent pressure limiting valve used in DAF (1236573), MAN (81.52110-6101), MERCEDES BENZ (004 429 81 44), RENAULT TRUCKS (7403181898), VOLVO (1932736, 3181898), and WABCO (434 100 082 0) systems. This component is essential for maintaining the correct pressure thresholds across various heavy commercial vehicle platforms, including FREIGHTLINER, IVECO, KENWORTH, MACK, PETERBILT, and STEYR.
For workshop technicians, this unit features standardized M22x1.5 ports for reliable assembly and seamless integration into the existing pneumatic circuit. Regular inspection of the return function and pressure thresholds is recommended during routine brake system maintenance to ensure long-term reliability and prevent system failures in heavy commercial vehicles.
Technical Specifications
| Port 1 | M22x1.5 |
|---|---|
| Port 2 | M22x1.5 |
| Pressure | 4.8-0.3 Bar |
| Return | OK |
Other OEMs
DAF
- 1236573
MAN
- 81521106101
- 81.52110-6101
MERCEDES BENZ
- A0044298144
- 004 429 81 44
RENAULT TRUCKS
- 7403181898
VOLVO
- 3181898
- 1932736
WABCO
- 4341000820
- 434 100 082 0
Vehicles Used
| Brand | Model | Engine |
|---|---|---|
| DAF | ||
| FREIGHTLINER | ||
| IVECO | ||
| KENWORTH | ||
| MACK | ||
| MAN | ||
| MERCEDES BENZ | ||
| MERITOR | ||
| PETERBILT | ||
| RENAULT TRUCKS | ||
| STEYR | ||
| VOLVO | ||
| WABCO |
