1300 340 001 Volvo Compatible Single Cylinder Compressor
1300 340 001
Summary
High-performance water-cooled single cylinder air compressor designed for Volvo heavy commercial vehicles. Features a Ø88.00 mm cylinder bore, 35 mm stroke, and 213cm³ swept volume for reliable pneumatic system pressure. Equivalent to OE Knorr-Bremse I85028 and Volvo 5003219.
| EAN Code | 8699031078366 |
|---|
Ready to Order
Compatible OEM Codes
-
VOLVO
- 6795600
- 6772239
- 5009219
- 5003219
-
KNORR-BREMSE
- LK3802
- I85028
Description
What does a single cylinder compressor do?
This water-cooled single cylinder air compressor is engineered to provide consistent air pressure for heavy-duty braking systems. Built with high-strength components, it ensures reliable performance under demanding thermal conditions, preventing overheating during continuous operation.Vehicle and engine compatibility
This component is specifically fitted to Volvo trucks including models F7, F10, F12, N10, and N12. It is compatible with various engine configurations such as TD70, TD71, TD100, TD101, TD120, TD121, and TD122. It is also suitable for Volvo B10M and B12 engines.Installation and maintenance guidance
The unit features a through-drive design and includes a water-cooled valve plate to maintain optimal operating temperatures. Technical specifications include an air inlet and outlet port of M26x1.5, with water ports sized at M22x1.5. Maintenance should focus on ensuring the cooling lines are clear and the drive mechanism remains properly aligned.Selection guidance
When replacing this unit, verify the cooling type and port sizes to ensure correct integration with the existing engine system. Consult your authorized distributor for further assistance.OE cross-reference
1300 340 001 (Single Cylinder Compressor) is the equivalent of the Knorr-Bremse and Volvo OE numbers. This part directly replaces Knorr-Bremse OE numbers I85028, LK3802. It also replaces Volvo OE numbers 5003219, 5009219, 6772239, 6795600.Technical Specifications
| Cylinder Bore | Ø88.00 |
|---|---|
| Stroke | 35 mm |
| Swept Volume | 213cm³ |
| Air Inlet Port | M26x1,5 |
| Air Outlet Port | M26x1,5 |
| Number of Cylinders | 1 |
| Through Drive | OK |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | M22x1,5 |
| Water Outlet Port | M22x1,5 |
| Water Cooled Valve Plate | OK |
| Weight | 11,5 KG |
Other OEMs
KNORR-BREMSE
- LK3802
- I85028
VOLVO
- 6795600
- 6772239
- 5009219
- 5003219
Related Products
Repair Kits
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| KNORR-BREMSE | |||
| VOLVO | |||
| VOLVO | B10M | TD100 | |
| VOLVO | B12 | TD120 | |
| VOLVO | F10 | TD100 | |
| VOLVO | F10 | TD101 | |
| VOLVO | F12 | TD120 | |
| VOLVO | F12 | TD121 | |
| VOLVO | F12 | TD122 | |
| VOLVO | F7 | TD70 | |
| VOLVO | F7 | TD71 | |
| VOLVO | N10 | TD100 | |
| VOLVO | N10 | TD101 | |
| VOLVO | N12 | TD120 | |
| VOLVO | N12 | TD122 |
FAQ
How does the cooling system work on this compressor?
This is a water-cooled unit that utilizes a water inlet and outlet port (M22x1.5) to manage thermal loads during operation.
Which Volvo models are compatible with this part?
It is designed for Volvo F7, F10, F12, N10, N12, B10M, and B12 trucks with corresponding engine series.
What are the key technical specifications?
The unit features a Ø88.00 mm cylinder bore, a 35 mm stroke, and a 213cm³ swept volume.
Can I use this as an equivalent to Knorr-Bremse parts?
Yes, this component is designed to meet the requirements of Knorr-Bremse systems in compatible heavy commercial vehicles.
What are the OE reference numbers of this part?
1300 340 001 directly replaces Knorr-Bremse OE numbers I85028, LK3802. It also replaces Volvo OE numbers 5003219, 5009219, 6772239, 6795600.
