1300 080 001 Compatible Single Cylinder Air Compressor
1300 080 001
Summary
This water-cooled single cylinder air compressor features a Ø88.00 mm bore, 35 mm stroke, and 213cm³ swept volume. It is designed for high-performance air production in heavy commercial vehicle brake systems and is compatible with Knorr-Bremse systems. Equivalent to OE Knorr-Bremse I94314.
| EAN Code | 8699031079233 |
|---|
Ready to Order
Compatible OEM Codes
-
KNORR-BREMSE
- LP3975
- LK3970
- LK3821
- LK3819
- LK3813
- LK3810
- K000743AT
- K000743
- II39522FAT
- II39522F
- II33509004
- II33509
- I98499
- I94314ATVO
- I94314AT000
- I94314AT
- I9431405T
- I94314000
- I94314
Description
What does a single cylinder air compressor do?
This single cylinder air compressor serves as a critical component in the pneumatic brake system of heavy commercial vehicles. By utilizing a piston-type mechanism, it compresses intake air and directs it toward the air processing unit and storage tanks to ensure consistent pressure for braking operations. This unit is engineered with heavy-duty grade materials to withstand the rigorous thermal and mechanical stresses of continuous service.Vehicle compatibility and technical design
The design is highly efficient for applications requiring reliable air delivery, particularly in vehicles where space and weight optimization are essential. This specific model is compatible with Knorr-Bremse systems and features water-cooling ports (M22x1,5) to maintain optimal operating temperatures during heavy-duty cycles. Its compact architecture makes it a reliable choice for various heavy commercial vehicle configurations.Installation and maintenance guidance
For proper installation, technicians should ensure that the water inlet and outlet ports are correctly aligned to prevent overheating. Given the Ø88.00 mm bore and M26x1,5 air ports, precise mounting is necessary to prevent vibration or leaks. Regular inspection of the cooling lines and air connections is recommended to maintain peak system efficiency.Troubleshooting advice
If air pressure builds slowly or if there is an unusual noise during compression, the unit may require inspection or replacement to prevent brake system failure.OE cross-reference
1300 080 001 (Single Cylinder Compressor) is the equivalent of the Knorr-Bremse OE numbers. This part directly replaces Knorr-Bremse OE numbers I94314, I94314000, I9431405T, I94314AT, I94314AT000, I94314ATVO, I98499, II33509, II33509004, II39522F, II39522FAT, K000743, K000743AT, LK3810, LK3813, LK3819, LK3821, LK3970, LP3975.Technical Specifications
| Cylinder Bore | Ø88.00 |
|---|---|
| Stroke | 35 mm |
| Swept Volume | 213cm³ |
| Air Inlet Port | M26x1,5 |
| Air Outlet Port | M26x1,5 |
| Number of Cylinders | 1 |
| Through Drive | OK |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | M22x1,5 |
| Water Outlet Port | M22x1,5 |
| Weight | 11,1 KG |
Other OEMs
KNORR-BREMSE
- LP3975
- LK3970
- LK3821
- LK3819
- LK3813
- LK3810
- K000743AT
- K000743
- II39522FAT
- II39522F
- II33509004
- II33509
- I98499
- I94314ATVO
- I94314AT000
- I94314AT
- I9431405T
- I94314000
- I94314
Related Products
Repair Kits
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| KNORR-BREMSE |
FAQ
What is the primary function of this single cylinder compressor?
It compresses intake air to provide the necessary pressure for the pneumatic brake system in heavy commercial vehicles, ensuring reliable braking performance.
Is this compressor water-cooled or air-cooled?
This specific model is a water-cooled unit, featuring M22x1,5 water inlet and outlet ports to manage operating temperatures effectively.
What are the key technical specifications for this unit?
The unit features a Ø88.00 mm cylinder bore, a 35 mm stroke, a 213cm³ swept volume, and weighs approximately 11.1 kg.
Which brands is this component compatible with?
This component is designed to be compatible with Knorr-Bremse systems used in various heavy commercial vehicle applications.
What are the OE reference numbers of this part?
1300 080 001 directly replaces Knorr-Bremse OE numbers I94314, I94314000, I9431405T, I94314AT, I94314AT000, I94314ATVO, I98499, II33509, II33509004, II39522F, II39522FAT, K000743, K000743AT, LK3810, LK3813, LK3819, LK3821, LK3970, LP3975.
