0103 323 Compatible Split Cylinder for DAF, Iveco, MAN

What does a split cylinder do?

This split cylinder serves as a critical component within the transmission system of heavy commercial vehicles. It facilitates the precise pneumatic piston actuation required for splitter/range gearbox operations, ensuring smooth shifting transitions between gear ranges. Built with high-strength components, it maintains operational integrity under the rigorous demands of heavy-duty driving cycles.

Vehicle and system compatibility

This component is specifically designed to be compatible with DAF, Iveco, and MAN vehicles. It also serves as an equivalent for various ZF systems used in heavy commercial vehicle transmissions. These units are essential for maintaining the shifting accuracy of the gearbox in trucks and tractors.

Installation and maintenance

Maintenance of the splitter cylinder involves checking the pneumatic air fittings and ensuring the seals remain intact to prevent pressure loss. Technicians should inspect the mechanical linkage and air lines during routine gearbox service to prevent shifting delays or improper range selection.

Troubleshooting and selection

Proper selection of this split cylinder ensures optimal performance within the transmission assembly. When replacing this part, verify that the pneumatic connections are secure to maintain consistent piston movement throughout the shifting cycle.

OE cross-reference

0103 323 (Split Cylinder Split Cylinders) is the equivalent of the DAF, Iveco, MAN and ZF OE numbers. This part directly replaces DAF OE number 1291002. It also replaces Iveco OE number 93190570, MAN OE number 81326380024 and ZF OE number 1315334021.
