303.05.0022 Compatible Trailer Control Valve
303.05.0022
Summary
Reliable trailer control valve compatible with DAF, Iveco, and Renault Trucks. Features multiple M16x1,5 ports for precise pneumatic connection in heavy commercial vehicle air brake systems. Equivalent to OE DAF 1506482, Iveco 61605099 and Renault Trucks 5000450588.
| EAN Code | 8683457009936 |
|---|
Ready to Order
Compatible OEM Codes
-
WABCO
- 973 002 550 0
- 973 002 525 0
-
RENAULT TRUCKS
- 5000450588
-
IVECO
- 61605099
-
DAF
- 1506482
Description
What does a trailer control valve do?
This trailer control valve plays a critical role in the pneumatic braking system of heavy commercial vehicles. It functions by balancing the air pressure delivered to the trailer based on the driver's input, ensuring consistent braking performance across tractor-trailer combinations. Built with high-strength components, this valve is designed to withstand demanding operating conditions in the air brake line.Vehicle and system compatibility
The unit is compatible with DAF, Iveco, and Renault Trucks. It is also fitted to other heavy commercial vehicles utilizing similar pneumatic architectures. This component is designed for seamless integration into existing systems, providing a reliable solution for maintaining optimal braking pressure during heavy-duty transit.Installation and maintenance guidance
Installation requires careful attention to the M16x1,5 port connections (Ports 11, 12, 22, 41, 42, and 43) to ensure an airtight seal. Workshop technicians should inspect all pneumatic lines and sealing surfaces during installation to prevent pressure drops. Periodic inspection of the valve body is recommended to maintain system integrity.Troubleshooting and selection
When troubleshooting braking delays or uneven pressure distribution between axles, this valve should be evaluated as a potential cause. Maintaining correct air pressure levels within the system ensures the safety and efficiency of the vehicle's braking response. Consult your authorized distributor.OE cross-reference
303.05.0022 (Trailer Control Valve) is the equivalent of the DAF, Iveco, Renault Trucks and WABCO OE numbers. This part directly replaces DAF OE number 1506482. It also replaces Iveco OE number 61605099, Renault Trucks OE number 5000450588 and WABCO OE numbers 9730025250, 9730025500.Technical Specifications
| Port 12 | M16x1,5 |
|---|---|
| Port 22 | M16x1,5 |
| Port 11 | M16x1,5 |
| Port 41 | M16x1,5 |
| Port 42 | M16x1,5 |
| Port 43 | M16x1,5 |
Other OEMs
DAF
- 1506482
IVECO
- 61605099
RENAULT TRUCKS
- 5000450588
WABCO
- 9730025500
- 9730025250
- 973 002 550 0
- 973 002 525 0
Related Products
Repair Kits
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| DAF | |||
| IVECO | |||
| RENAULT TRUCKS | |||
| WABCO |
FAQ
What is the function of a trailer control valve?
It balances air pressure delivered to a trailer based on brake pedal input and provides quick-release exhaust for efficient braking.
Which vehicles are compatible with this valve?
This part is compatible with DAF, Iveco, and Renault Trucks vehicles within heavy commercial sectors.
What are the port specifications for this component?
This unit features several M16x1,5 ports (including Ports 11, 12, 22, 41, 42, and 43) for pneumatic connections.
How can I ensure the correct fitment for my truck?
Before installation, verify compatibility using the vehicle's chassis number or by checking the original part's specification.
What are the OE reference numbers of this part?
303.05.0022 directly replaces DAF OE number 1506482. It also replaces Iveco OE number 61605099, Renault Trucks OE number 5000450588 and WABCO OE numbers 9730025250, 9730025500.
