303.01.0040 Relay Valve, Brake System

2654 Views Updated

303.01.0040 Relay Valve for Scania and Iveco

303.01.0040

Summary

This relay valve features M22x1.5 and M16x1.5 port configurations, designed for heavy-duty air brake systems. It ensures rapid air pressure transfer for reliable braking performance in Scania, Iveco, and other commercial vehicles. Check the compatibility list. Equivalent to OE Faun 99707005415, Iveco 41025604 and Leyland EXABR303.

Product identifiers
EAN Code8683457009226
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Compatible OEM Codes

  • IVECO
    • 5801101682
    • 41025604
  • WABCO
    • 973 011 203 0
  • VOLKSWAGEN TRUCK
    • 2TA 607 409
  • VAN HOOL
    • 10833312
  • SCANIA
    • 2090240
  • LIEBHERR
    • 502661508
  • LEYLAND
    • EXABR303
  • FAUN
    • 99707005415

Description

What does a relay valve do?

This relay valve plays a critical role in the compressed air brake system of heavy commercial vehicles by ensuring rapid air pressure transfer triggered by a pilot signal. Built with high-strength components, it is designed to withstand demanding operating conditions while maintaining precise control over braking forces.

Vehicle and system compatibility

The unit is compatible with Scania, Iveco, Faun, Leyland, Liebherr, Van Hool, and Volkswagen Truck vehicles. It is also engineered to work with WABCO systems to ensure seamless integration within the pneumatic braking circuit.

Installation and maintenance

For proper installation, technicians should verify that the M22x1.5 and M16x1.5 ports are correctly aligned with the chassis connections. This component operates at a maximum pressure of 10 BAR and should be inspected during routine brake system maintenance to prevent pressure loss.

Operational requirements

When replacing this valve, ensure the mounting location between the main air reservoir and the brake chambers is clear of debris to maintain optimal performance.

OE cross-reference

303.01.0040 (Relay Valve Relay Valves) is the equivalent of the Faun, Iveco, Leyland, Liebherr, Scania, Van Hool, Volkswagen Truck and WABCO OE numbers. This part directly replaces Faun OE number 99707005415. It also replaces Iveco OE numbers 41025604, 5801101682, Leyland OE number EXABR303, Liebherr OE number 502661508, Scania OE number 2090240, Van Hool OE number 10833312, Volkswagen Truck OE number 2TA607409 and WABCO OE number 9730112030.

Technical Specifications

Technical Specifications
Port 1M22x1,5
Port 2M22x1,5
Port 41M16x1,5
Port 42M16x1,5
PressureMAX 10 BAR

Other OEMs

FAUN

  • 99707005415

IVECO

  • 5801101682
  • 41025604

LEYLAND

  • EXABR303

LIEBHERR

  • 502661508

SCANIA

  • 2090240

VAN HOOL

  • 10833312

VOLKSWAGEN TRUCK

  • 2TA607409
  • 2TA 607 409

WABCO

  • 9730112030
  • 973 011 203 0

Related Products

Similar Products

Compatible Vehicles

Compatible Vehicles
BrandModelModel TypeEngine
FAUN
IVECO
LEYLAND
LIEBHERR
SCANIA
VAN HOOL
VOLKSWAGEN TRUCK
WABCO

FAQ

What is the function of this relay valve?
It facilitates rapid air pressure transfer within the pneumatic braking system when triggered by a pilot signal, ensuring timely brake engagement.
Which vehicle brands is this part compatible with?
This component is designed for Scania, Iveco, Faun, Leyland, Liebherr, Van Hool, and Volkswagen Truck commercial vehicles.
What are the port specifications for this component?
The valve features Port 1 and Port 2 as M22x1.5, while Port 41 and Port 42 are M16x1.5.
What is the maximum operating pressure?
The relay valve is designed to operate safely at a maximum pressure of 10 BAR.
What are the OE reference numbers of this part?
303.01.0040 directly replaces Faun OE number 99707005415. It also replaces Iveco OE numbers 41025604, 5801101682, Leyland OE number EXABR303, Liebherr OE number 502661508, Scania OE number 2090240, Van Hool OE number 10833312, Volkswagen Truck OE number 2TA607409 and WABCO OE number 9730112030.
