301.07.0167 Equivalent Pressure Limiting Valve
301.07.0167
Summary
This pressure limiting valve is designed for heavy commercial vehicle brake systems. It features M22x1.5 ports, a non-return function, and operates within an 8-0.3 bar pressure range to ensure precise pneumatic regulation in demanding environments. Equivalent to OE WABCO 4341006000.
| EAN Code | 8683457046665 |
|---|
Ready to Order
Compatible OEM Codes
-
WABCO
- 434 100 600 0
Description
What does a pressure limiting valve do?
This pressure limiting valve serves as a critical component within the pneumatic brake system, ensuring that pressure levels remain within safe operating parameters. By regulating air pressure, it protects downstream components and maintains the stability of the braking force during operation.Compatibility and technical specifications
The component is designed to be compatible with WABCO systems and is built using high-strength components to withstand heavy-duty service conditions. It features M22x1.5 ports on both sides and includes a non-return functionality to prevent backflow within the pneumatic circuit.Installation and maintenance
For proper maintenance, technicians should regularly inspect the M22x1.5 connections and verify that the 8-0.3 bar pressure regulation remains consistent. Ensuring that the non-return mechanism functions correctly is vital for preventing air loss and maintaining system integrity.System reliability
Consult your authorized distributor to ensure correct fitment for your specific heavy commercial vehicle application.OE cross-reference
301.07.0167 (Pressure Limiting Valve) is the equivalent of the WABCO OE number. This part directly replaces WABCO OE number 4341006000.Technical Specifications
| Port 1 | M22x1.5 |
|---|---|
| Port 2 | M22x1.5 |
| Pressure | 8-0.3 Bar |
| Non-Return | OK |
Other OEMs
WABCO
- 4341006000
- 434 100 600 0
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| WABCO |
FAQ
What is the function of this pressure limiting valve?
It regulates air pressure within the brake system to ensure it stays within safe limits, protecting the pneumatic circuit.
What are the port specifications for this component?
The valve is equipped with M22x1.5 ports on both sides for standardized installation in commercial systems.
Does this valve include a non-return feature?
Yes, this model includes a non-return function to help maintain stable air pressure and prevent backflow.
What is the operating pressure range?
The component is designed to operate effectively within a pressure range of 8-0.3 bar.
What are the OE reference numbers of this part?
301.07.0167 directly replaces WABCO OE number 4341006000.
