301.07.0122 Bosch Compatible Pressure Limiting Valve
301.07.0122
Summary
This heavy-duty pressure limiting valve is designed for precise pneumatic control within brake systems. It features M16x1.5 port sizes and a limited transition pressure of 8.1 BAR, ensuring reliable pressure regulation for heavy commercial vehicle applications. Equivalent to OE Bosch 0481009061.
| EAN Code | 8683457010697 |
|---|
Ready to Order
Compatible OEM Codes
-
BOSCH
- 0 481 009 061
Description
What does a pressure limiting valve do?
This pressure limiting valve serves as a critical component within the pneumatic brake system, regulating air pressure to ensure optimal braking performance and safety. Manufactured with high-strength components, it is engineered to withstand the rigorous operating conditions found in heavy commercial vehicle braking systems.Technical specifications and compatibility
The component is compatible with Bosch systems and features specific technical parameters, including M16x1.5 port sizes for both Port 1 and Port 2. It maintains a limited transition pressure of 8.1 BAR and a safety pressure rating of 10.5 BAR + 2.5 BAR to ensure system stability under varying loads.Installation and maintenance guidance
For workshop technicians, ensuring correct installation of these valves is essential for maintaining pneumatic integrity. It is recommended to inspect the M16x1.5 connections and check the transition pressure settings during routine brake system maintenance to prevent pressure surges.Selection and troubleshooting
Consult your authorized distributor to verify exact fitment for your specific heavy commercial vehicle configuration.OE cross-reference
301.07.0122 (Pressure Limiting Valve) is the equivalent of the Bosch OE number. This part directly replaces Bosch OE number 0481009061.Technical Specifications
| Port 1 | M16x1,5 |
|---|---|
| Port 2 | M16x1,5 |
| Limited Transition Pressure | 8,1 BAR |
| Safety Pressure | 10,5 BAR + 2,5 BAR |
Other OEMs
BOSCH
- 0481009061
- 0 481 009 061
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| BOSCH |
FAQ
What is the function of this pressure limiting valve?
It regulates air pressure within the brake system, ensuring that the pneumatic lines operate within safe limits by managing the transition pressure.
What are the port specifications for this component?
This valve is equipped with M16x1.5 ports on both Port 1 and Port 2 for standard pneumatic connections.
How does the transition pressure work?
The unit is designed with a limited transition pressure of 8.1 BAR to maintain steady air distribution across the braking circuit.
What should I check if the braking system has irregular pressure?
Technicians should inspect the valve's ports and verify if the safety pressure levels (10.5 BAR + 2.5 BAR) align with the vehicle's requirements.
What are the OE reference numbers of this part?
301.07.0122 directly replaces Bosch OE number 0481009061.
