301.07.0120 Pressure Limiting Valve for Bosch Systems
301.07.0120
Summary
This pressure limiting valve is designed for heavy commercial vehicle brake systems. It features M22x1.5 ports and a limited transition pressure of 10.0 BAR + 0.2 BAR, ensuring precise pressure regulation in high-demand environments. Compatible with Bosch systems. Equivalent to OE Bosch 0481009056.
| EAN Code | 8683457010673 |
|---|
Ready to Order
Compatible OEM Codes
-
BOSCH
- 0 481 009 056
Description
What does a pressure limiting valve do?
This pressure limiting valve plays a critical role in regulating pneumatic pressure within the braking system of heavy commercial vehicles. By maintaining the correct pressure thresholds, it prevents system over-pressurization and ensures consistent braking performance under varying loads.Compatibility and build quality
This component is compatible with Bosch systems and is built using high-strength components to withstand heavy-duty operational cycles. Its precise mechanism ensures that the pressure transition remains stable during intensive use.Installation and technical specifications
The unit is specified with M22x1.5 ports for Port 1 and Port 2, providing a secure connection within the pneumatic circuit. Technicians should verify the 10.0 BAR + 0.2 BAR transition pressure setting to ensure it matches the specific requirements of the vehicle's braking architecture during installation.Maintenance and troubleshooting
Regular inspection of the valve assembly can prevent sudden drops in system pressure. When replacing this component, ensure all connections are torqued correctly to maintain the integrity of the pneumatic lines.OE cross-reference
301.07.0120 (Pressure Limiting Valve) is the equivalent of the Bosch OE number. This part directly replaces Bosch OE number 0481009056.Technical Specifications
| Port 1 | M22x1,5 |
|---|---|
| Port 2 | M22x1,5 |
| Limited Transition Pressure | 10,0 BAR + 0,2 BAR |
| Safety Pressure | - |
Other OEMs
BOSCH
- 0481009056
- 0 481 009 056
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| BOSCH |
FAQ
What is the function of this pressure limiting valve?
It regulates air pressure within the braking system to ensure that pressures do not exceed safe operating limits, maintaining stability for heavy commercial vehicles.
What are the port specifications for this component?
This specific model is equipped with M22x1.5 ports on both Port 1 and Port 2 for secure pneumatic integration.
How is the transition pressure defined?
The valve features a limited transition pressure of 10.0 BAR + 0.2 BAR, which is critical for accurate brake system modulation.
Which brands is this valve compatible with?
This component is designed to be compatible with Bosch systems in heavy commercial vehicle applications.
What are the OE reference numbers of this part?
301.07.0120 directly replaces Bosch OE number 0481009056.
