301.07.0117 Pressure Limiting Valve for Bosch Systems
301.07.0117
Summary
This heavy-duty pressure limiting valve is designed for brake system applications. It features M22x1.5 ports, a 7.4 BAR limited transition pressure, and a safety pressure of 10.0 BAR ± 0.5 BAR. High-strength components ensure reliable performance in demanding commercial vehicle environments. Equivalent to OE Bosch 0481009050.
| EAN Code | 8683457010642 |
|---|
Ready to Order
Compatible OEM Codes
-
BOSCH
- 0 481 009 050
Description
What does a pressure limiting valve do?
This pressure limiting valve plays a critical role in regulating pneumatic pressure within the braking system of heavy commercial vehicles. By maintaining specific pressure thresholds, it ensures the stability and safety of the pneumatic circuit under varying load conditions.System compatibility and specifications
The component is designed to be compatible with Bosch systems and is engineered to meet high-performance standards for heavy-duty applications. It features M22x1.5 port connections and provides a precise limited transition pressure of 7.4 BAR to maintain optimal system regulation.Installation and maintenance guidance
For professional workshop technicians, proper installation is key to ensuring system integrity. When replacing this component, verify that the M22x1.5 threads are clean and that the safety pressure of 10.0 BAR ± 0.5 BAR matches the vehicle's original technical requirements to prevent overpressure scenarios.Operational reliability
Regular inspection of the valve assembly can prevent unexpected pressure drops or leaks in the pneumatic line. Maintaining these high-strength components ensures consistent braking performance for fleet managers and heavy commercial vehicle operators alike.OE cross-reference
301.07.0117 (Pressure Limiting Valve) is the equivalent of the Bosch OE number. This part directly replaces Bosch OE number 0481009050.Technical Specifications
| Port 1 | M22x1,5 |
|---|---|
| Port 2 | M22x1,5 |
| Limited Transition Pressure | 7,4 BAR |
| Safety Pressure | 10,0 BAR ± 0,5 BAR |
Other OEMs
BOSCH
- 0481009050
- 0 481 009 050
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| BOSCH |
FAQ
What is the function of this pressure limiting valve?
It regulates pneumatic pressure within the brake system, ensuring that the transition occurs at 7.4 BAR to maintain safe operating levels.
What are the port specifications for this component?
This valve is equipped with M22x1.5 ports on both sides to ensure secure and standardized connection within the pneumatic circuit.
How is the safety pressure defined for this part?
The component is designed with a safety pressure rating of 10.0 BAR ± 0.5 BAR to protect the braking system from excessive pneumatic force.
Which brands is this valve compatible with?
This specific part is designed to be compatible with Bosch systems used in heavy commercial vehicle braking applications.
What are the OE reference numbers of this part?
301.07.0117 directly replaces Bosch OE number 0481009050.
