301.07.0110 Pressure Limiting Valve for Bosch systems
301.07.0110
Summary
This pressure limiting valve is engineered for heavy commercial vehicle brake systems. It features M16x1.5 ports and a 2.4 BAR limited transition pressure to ensure precise pneumatic control and system safety in demanding environments. Equivalent to OE Bosch 0481009034.
| EAN Code | 8683457010574 |
|---|
Ready to Order
Compatible OEM Codes
-
BOSCH
- 0 481 009 034
Description
What does a pressure limiting valve do?
This pressure limiting valve plays a critical role in maintaining stable pneumatic pressure within the braking system. By regulating the transition pressure, it ensures that air pressure remains within safe operational limits, preventing over-pressurization during heavy-duty braking cycles.Compatibility and application
Designed for compatibility with Bosch systems, this component is essential for maintaining the integrity of the pneumatic circuit. It is specifically engineered to handle the rigorous demands of heavy commercial vehicle brake systems.Installation and maintenance
The unit is equipped with M16x1.5 ports on both sides to facilitate secure and leak-free connections. Technicians should verify the 2.4 BAR transition pressure setting during installation to ensure alignment with specific system requirements.Troubleshooting guidance
Regular inspection of the valve ports and seals is recommended to prevent pressure drops. For optimal performance, check for any signs of debris or wear around the M16x1.5 connection points during routine maintenance intervals.OE cross-reference
301.07.0110 (Pressure Limiting Valve) is the equivalent of the Bosch OE number. This part directly replaces Bosch OE number 0481009034.Technical Specifications
| Port 1 | M16x1,5 |
|---|---|
| Port 2 | M16x1,5 |
| Limited Transition Pressure | 2,4 BAR |
| Safety Pressure | - |
Other OEMs
BOSCH
- 0481009034
- 0 481 009 034
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| BOSCH |
FAQ
What is the function of this pressure limiting valve?
It regulates pneumatic pressure within the brake system by managing the transition at a specific threshold, ensuring the system operates within safe limits.
What are the connection specifications for this part?
This component features two M16x1.5 ports designed for secure integration into professional pneumatic brake circuits.
What is the transition pressure for this component?
The valve is designed with a limited transition pressure of 2.4 BAR to maintain precise control within the braking system.
How can I identify if the valve needs replacement?
Technicians should look for inconsistent braking response or visible air leaks around the M16x1.5 ports which may indicate a failure in pressure regulation.
What are the OE reference numbers of this part?
301.07.0110 directly replaces Bosch OE number 0481009034.
