301.07.0106 Pressure Limiting Valve for Bosch Systems
301.07.0106
Summary
This heavy-duty pressure limiting valve features M22x1,5 port connections and a 5,9 BAR limited transition pressure. It is designed for reliable performance in brake systems and is compatible with Bosch systems. Equivalent to OE Bosch 0481009026.
| EAN Code | 8683457010536 |
|---|
Ready to Order
Compatible OEM Codes
-
BOSCH
- 0 481 009 026
Description
What does a pressure limiting valve do?
This pressure limiting valve serves a critical role in maintaining regulated pneumatic pressure within the brake system. By controlling the transition at 5,9 BAR, it ensures that the system operates within safe and functional parameters, protecting downstream components from overpressure conditions.Compatibility and application
This component is engineered for durability and precision in heavy commercial vehicle brake systems. It is compatible with Bosch systems and ensures consistent pressure regulation during operation.Installation and maintenance
The unit is designed with M22x1,5 ports to ensure secure fitment and minimal leakage. Technicians should inspect the port threads and seals during installation to maintain the integrity of the pneumatic circuit.System troubleshooting
Regular inspection of the valve's response to pressure changes can help prevent system failures. For optimal performance, ensure the valve is free from contaminants that could interfere with the internal spring mechanism.OE cross-reference
301.07.0106 (Pressure Limiting Valve) is the equivalent of the Bosch OE number. This part directly replaces Bosch OE number 0481009026.Technical Specifications
| Port 1 | M22x1,5 |
|---|---|
| Port 2 | M22x1,5 |
| Limited Transition Pressure | 5,9 BAR |
| Safety Pressure | - |
Other OEMs
BOSCH
- 0481009026
- 0 481 009 026
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| BOSCH |
FAQ
What is the function of this pressure limiting valve?
It regulates system pressure by managing the transition at 5,9 BAR, ensuring the brake system operates within safe limits.
What port sizes does this component use?
This valve is equipped with M22x1,5 ports for standard industrial pneumatic connections.
Is this valve compatible with Bosch systems?
Yes, this component is designed to be compatible with Bosch systems used in heavy commercial vehicles.
How can I identify if the valve needs replacement?
Technicians should look for signs of air leakage around the M22x1,5 ports or a failure to maintain the 5,9 BAR threshold.
What are the OE reference numbers of this part?
301.07.0106 directly replaces Bosch OE number 0481009026.
