301.07.0105 Pressure Limiting Valve for Bosch Systems
301.07.0105
Summary
This pressure limiting valve features M22x1.5 ports and a 7.2 BAR limited transition pressure. Designed for heavy commercial vehicle brake systems, it ensures precise pressure regulation within the pneumatic circuit. This component is compatible with Bosch systems. Equivalent to OE Bosch 0481009025.
| EAN Code | 8683457010529 |
|---|
Ready to Order
Compatible OEM Codes
-
BOSCH
- 0 481 009 025
Description
What does a pressure limiting valve do?
This pressure limiting valve plays a critical role in the pneumatic brake system by regulating air pressure levels to ensure safe and consistent operation. Built with high-strength components, it is designed to manage pressure transitions effectively under demanding heavy commercial vehicle service conditions.System compatibility and function
This component is compatible with Bosch systems and is engineered to meet strict technical requirements for pneumatic reliability. It functions as a vital safety element within the air brake circuit, preventing over-pressurization in downstream components.Installation and technical specifications
The unit features M22x1.5 port sizes on both sides and is calibrated for a 7.2 BAR limited transition pressure. Technicians should verify all connection points and ensure that the installation aligns with the existing pneumatic lines to maintain system integrity.Maintenance guidance
For optimal performance, regular inspections of the valve ports and seals are recommended during routine brake system maintenance to prevent air leaks.OE cross-reference
301.07.0105 (Pressure Limiting Valve) is the equivalent of the Bosch OE number. This part directly replaces Bosch OE number 0481009025.Technical Specifications
| Port 1 | M22x1,5 |
|---|---|
| Port 2 | M22x1,5 |
| Limited Transition Pressure | 7,2 BAR |
| Safety Pressure | - |
Other OEMs
BOSCH
- 0481009025
- 0 481 009 025
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| BOSCH |
FAQ
What is the function of this pressure limiting valve?
It regulates air pressure within the pneumatic brake system, specifically managing the transition at 7.2 BAR to protect the circuit.
What are the connection specifications for this component?
The valve is equipped with M22x1.5 ports on both Port 1 and Port 2 for secure pneumatic connections.
Is this valve compatible with Bosch systems?
Yes, this component is designed to be compatible with Bosch systems used in heavy commercial vehicle applications.
What should I check during installation?
Ensure all M22x1.5 threads are clean and that the 7.2 BAR transition threshold matches your system's operational requirements.
What are the OE reference numbers of this part?
301.07.0105 directly replaces Bosch OE number 0481009025.
