301.07.0104 Pressure Limiting Valve for Bosch systems
301.07.0104
Summary
This pressure limiting valve is engineered for heavy commercial vehicle brake systems. It features M22x1,5 port connections and a limited transition pressure of 8.1 BAR, ensuring stable pneumatic regulation in high-pressure environments. Equivalent to OE Bosch 0481009023.
| EAN Code | 8683457010512 |
|---|
Ready to Order
Compatible OEM Codes
-
BOSCH
- 0 481 009 023
Description
What does a pressure limiting valve do?
This pressure limiting valve plays a critical role in regulating pneumatic pressure within the braking system. By managing pressure transitions, it ensures that the system operates within safe parameters, protecting downstream components from excessive pressure spikes.Compatibility and technical specifications
The component is designed to be compatible with Bosch systems. It features two M22x1,5 ports and is calibrated to a limited transition pressure of 8.1 BAR to maintain consistent performance across various operating conditions.Installation and maintenance
For proper installation, technicians should verify that the M22x1,5 thread connections are clean and free of debris. Ensuring the valve is correctly oriented within the pneumatic circuit is essential for maintaining the intended 8.1 BAR transition threshold.Troubleshooting guidance
Regular inspection of the valve housing and connections can help prevent leaks or pressure drops in the braking circuit. If fluctuations in system pressure are observed, consult your authorized distributor.OE cross-reference
301.07.0104 (Pressure Limiting Valve) is the equivalent of the Bosch OE number. This part directly replaces Bosch OE number 0481009023.Technical Specifications
| Port 1 | M22x1,5 |
|---|---|
| Port 2 | M22x1,5 |
| Limited Transition Pressure | 8,1 BAR |
| Safety Pressure | - |
Other OEMs
BOSCH
- 0481009023
- 0 481 009 023
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| BOSCH |
FAQ
What is the function of this pressure limiting valve?
It regulates pneumatic pressure within the brake system by managing transitions at a specific threshold to protect components.
What are the port specifications for this valve?
The unit is equipped with two M22x1,5 ports for secure pneumatic connections.
What is the transition pressure rating?
This specific valve is designed with a limited transition pressure of 8.1 BAR.
Which brands is this component compatible with?
This component is designed to be compatible with Bosch systems.
What are the OE reference numbers of this part?
301.07.0104 directly replaces Bosch OE number 0481009023.
