301.07.0100 Bosch compatible Pressure Limiting Valve
301.07.0100
Summary
This heavy-duty pressure limiting valve is designed for precision control within brake systems. Featuring M16x1,5 port sizes and a 7.3 BAR limited transition pressure, it ensures stable pneumatic performance for heavy commercial vehicle applications. Compatible with Bosch systems. Equivalent to OE Bosch 0481009019.
| EAN Code | 8683457010475 |
|---|
Ready to Order
Compatible OEM Codes
-
BOSCH
- 0 481 009 019
Description
What does a pressure limiting valve do?
This pressure limiting valve serves as a critical component in pneumatic brake systems by regulating air pressure levels to ensure safe and consistent operation. Built with high-strength components, it maintains system stability under heavy-duty working conditions.System compatibility and fitment
Designed to work seamlessly within specialized brake circuits, this unit is compatible with Bosch systems. It ensures that pressure levels remain within the required operational parameters to prevent system overpressure.Installation and maintenance
The valve features M16x1,5 ports for both Port 1 and Port 2, facilitating straightforward integration into existing pneumatic lines. Technicians should verify the 7.3 BAR limited transition pressure setting during installation to ensure correct system calibration.Operational stability
Regular inspection of the valve ports and connection points is recommended to prevent air leaks and maintain optimal braking performance throughout the service interval.OE cross-reference
301.07.0100 (Pressure Limiting Valve) is the equivalent of the Bosch OE number. This part directly replaces Bosch OE number 0481009019.Technical Specifications
| Port 1 | M16x1,5 |
|---|---|
| Port 2 | M16x1,5 |
| Limited Transition Pressure | 7,3 BAR |
| Safety Pressure | - |
Other OEMs
BOSCH
- 0481009019
- 0 481 009 019
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| BOSCH |
FAQ
What is the function of this pressure limiting valve?
It regulates pneumatic pressure within the brake system, ensuring that pressure does not exceed the designated 7.3 BAR transition limit.
What are the port specifications for this component?
This specific valve is equipped with M16x1,5 thread sizes on both Port 1 and Port 2 for secure pneumatic connections.
Is this valve compatible with Bosch systems?
Yes, this component is designed to be compatible with Bosch systems used in heavy commercial vehicle braking applications.
How can I identify a faulty pressure limiting valve?
Technicians should look for signs of erratic braking response or air leaks around the M16x1,5 ports that may indicate internal seal wear.
What are the OE reference numbers of this part?
301.07.0100 directly replaces Bosch OE number 0481009019.
