301.07.0094 Pressure Limiting Valve — Knorr-Bremse Equivalent
301.07.0094
Summary
This pressure limiting valve is designed for heavy commercial vehicle brake systems. It features M22x1.5 ports and maintains a limited transition pressure of 7.0 BAR ± 0.2 BAR and a safety pressure of 8.5 BAR ± 0.5 BAR, ensuring precise pneumatic control. Equivalent to OE Knorr-Bremse AC157M.
| EAN Code | 8683457010413 |
|---|
Ready to Order
Compatible OEM Codes
-
KNORR-BREMSE
- AC 157 M
Description
What does a pressure limiting valve do?
This pressure limiting valve serves as a critical component within the pneumatic brake system to regulate air pressure levels. By managing the transition between different pressure stages, it ensures that the braking force remains consistent and safe during operation. The unit is constructed from high-strength components to withstand demanding heavy commercial vehicle environments.System compatibility
This component is compatible with Knorr-Bremse systems and provides reliable performance under varying pneumatic loads. It is engineered to meet strict technical standards for heavy commercial vehicle safety and reliability.Installation and maintenance
For proper installation, technicians should verify that the M22x1.5 ports are correctly aligned with the existing lines to prevent leaks. Regular inspection of the 7.0 BAR transition threshold and the 8.5 BAR safety pressure limit is recommended to ensure the pneumatic circuit operates within specified parameters.Technical performance
Consult your authorized distributor.OE cross-reference
301.07.0094 (Pressure Limiting Valve) is the equivalent of the Knorr-Bremse OE number. This part directly replaces Knorr-Bremse OE number AC157M.Technical Specifications
| Port 1 | M22x1,5 |
|---|---|
| Port 2 | M22x1,5 |
| Limited Transition Pressure | 7,0 BAR ± 0,2 BAR |
| Safety Pressure | 8,5 BAR ± 0,5 BAR |
Other OEMs
KNORR-BREMSE
- AC157M
- AC 157 M
Related Products
Similar Products
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| KNORR-BREMSE |
FAQ
What is the primary function of this valve?
This valve regulates air pressure within the braking system by maintaining a specific transition pressure, ensuring safe and controlled deceleration.
What are the technical port specifications?
The unit features two M22x1.5 ports designed for secure pneumatic connections in heavy commercial vehicle systems.
What are the operating pressure limits?
The device operates with a limited transition pressure of 7.0 BAR ± 0.2 BAR and a safety pressure of 8.5 BAR ± 0.5 BAR.
Which systems is this valve compatible with?
This component is designed to be compatible with Knorr-Bremse systems used in heavy commercial vehicles.
What are the OE reference numbers of this part?
301.07.0094 directly replaces Knorr-Bremse OE number AC157M.
