301.07.0078 MAN Compatible Pressure Limiting Valve
301.07.0078
Summary
This high-strength pressure limiting valve is designed for heavy commercial vehicle brake systems. It features M22x1.5 VOSS ports and an adjustment range of 5.8 to 10.8 BAR, ensuring precise pressure regulation for MAN and WABCO systems. Equivalent to OE MAN 81521016295 and WABCO 4750103330.
| EAN Code | 8683457011830 |
|---|
Ready to Order
Compatible OEM Codes
-
WABCO
- 475 010 333 0
-
MAN
- 81.52101-6295
Description
What does a pressure limiting valve do?
This pressure limiting valve plays a critical role in maintaining stable pneumatic pressure within the heavy commercial vehicle brake system. By regulating the air flow, it prevents overpressure and ensures the braking components operate within their safe functional limits under heavy loads.Vehicle and system compatibility
The component is engineered to be compatible with MAN vehicles and WABCO systems. It operates with an inlet pressure of 12.5 BAR and provides an outlet pressure of 9.3 BAR, making it a reliable choice for demanding fleet operations.Installation and maintenance
Installation requires attention to the M22x1.5 VOSS port connections to ensure a leak-free seal. Technicians should verify the adjustment range of 5.8 to 10.8 BAR during assembly to match the specific requirements of the vehicle's pneumatic circuit.System reliability and selection
Regular inspection of the valve helps prevent sudden pressure drops or system instability. Consult your authorized distributor to ensure correct fitment for your specific heavy commercial vehicle application.OE cross-reference
301.07.0078 (Pressure Limiting Valve) is the equivalent of the MAN and WABCO OE numbers. This part directly replaces MAN OE number 81521016295. It also replaces WABCO OE number 4750103330.Technical Specifications
| Port 1 | M22x1,5 VOSS |
|---|---|
| Port 2 | M22x1,5 VOSS |
| Inlet Pressure | 12,5 BAR |
| Adjustment Range | 5,8 …..10,8 BAR |
| Outlet Pressure | 9,3 BAR |
Other OEMs
MAN
- 81521016295
- 81.52101-6295
WABCO
- 4750103330
- 475 010 333 0
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| MAN | |||
| WABCO |
FAQ
What is the primary function of this pressure limiting valve?
It regulates air pressure within the brake system to ensure it stays within a safe operating range, preventing component damage from overpressure.
Which vehicle makes is this valve compatible with?
This component is designed for use in MAN vehicles and is compatible with WABCO systems.
What are the technical connection specifications?
The valve features M22x1.5 VOSS ports for both the inlet and outlet connections.
What is the specified adjustment range for this unit?
The device features an adjustment range between 5.8 BAR and 10.8 BAR, with a standard inlet pressure of 12.5 BAR.
What are the OE reference numbers of this part?
301.07.0078 directly replaces MAN OE number 81521016295. It also replaces WABCO OE number 4750103330.
