301.07.0074 Pressure Limiting Valve, Brake System

890 Views Updated

301.07.0074 Compatible Pressure Limiting Valve — Scania

301.07.0074

Summary

This heavy-duty pressure limiting valve is designed for precision braking control. It features M22x1.5 ports, an inlet pressure of 7.5 BAR, and an adjustment range of 1.2 to 6.2 BAR to ensure optimal system performance in Scania and Langendorf vehicles. Equivalent to OE Langendorf 1111701, Scania 2090278 and WABCO 4750103100.

Product identifiers
EAN Code8683457011809
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Compatible OEM Codes

  • WABCO
    • 475 010 310 0
  • SCANIA
    • 2090278
  • LANGENDORF
    • 1111701

Description

What does a pressure limiting valve do?

This pressure limiting valve plays a critical role in regulating air pressure within the pneumatic brake system. By maintaining a stable outlet pressure of 4 BAR, it prevents system overpressure and ensures consistent braking force, which is essential for the safety of heavy commercial vehicles during operation.

Vehicle and engine compatibility

The component is engineered for high-strength durability and is compatible with Scania and Langendorf vehicles. It also serves as a reliable alternative for systems requiring precise pressure regulation across various heavy-duty applications.

Installation and maintenance

Installation requires careful attention to the M22x1.5 port connections to ensure a secure, airtight seal. Technicians should verify that the inlet pressure remains at 7.5 BAR and the adjustment range is set between 1.2 and 6.2 BAR according to the specific requirements of the vehicle's braking circuit.

Troubleshooting guidance

Regular inspection of the valve during routine maintenance can help prevent sudden pressure drops or leaks in the pneumatic lines. Consult your authorized distributor for fitment confirmation.

OE cross-reference

301.07.0074 (Pressure Limiting Valve) is the equivalent of the Langendorf, Scania and WABCO OE numbers. This part directly replaces Langendorf OE number 1111701. It also replaces Scania OE number 2090278 and WABCO OE number 4750103100.

Technical Specifications

Technical Specifications
Port 1M22x1,5
Port 2M22x1,5
Inlet Pressure7,5 BAR
Adjustment Range1,2 …..6,2 BAR
Outlet Pressure4 BAR

Other OEMs

LANGENDORF

  • 1111701

SCANIA

  • 2090278

WABCO

  • 4750103100
  • 475 010 310 0

Compatible Vehicles

Compatible Vehicles
BrandModelModel TypeEngine
LANGENDORF
SCANIA
WABCO

FAQ

What is the function of this pressure limiting valve?
It regulates the air pressure within the braking system, ensuring an outlet pressure of 4 BAR to maintain safe and consistent braking performance.
Which vehicles is this component compatible with?
This valve is compatible with Scania and Langendorf vehicles, specifically designed for heavy commercial vehicle braking systems.
What are the technical port specifications?
The valve features two M22x1.5 ports, designed to handle an inlet pressure of 7.5 BAR with an adjustable range from 1.2 to 6.2 BAR.
How can I identify if the valve needs replacement?
Technicians should look for signs of air leakage around the M22x1.5 ports or inconsistent braking performance caused by improper outlet pressure regulation.
What are the OE reference numbers of this part?
301.07.0074 directly replaces Langendorf OE number 1111701. It also replaces Scania OE number 2090278 and WABCO OE number 4750103100.
