301.07.0073 Pressure Limiting Valve, Brake System

1927 Views Updated

301.07.0073 Pressure Limiting Valve for Mercedes-Benz

301.07.0073

Summary

This pressure limiting valve is engineered for heavy commercial vehicle air brake systems. Featuring M22x1,5 ports, an inlet pressure of 7,5 BAR, and an adjustment range of 1,2 to 6,2 BAR, it ensures precise pressure regulation for Scania and Mercedes-Benz vehicles. Equivalent to OE Faun 1614112, Leyland EXABRB356 and Lohr A05021250.

Product identifiers
EAN Code8683457011793
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Compatible OEM Codes

  • WABCO
    • 475 010 309 0
  • SCANIA
    • 2090277
  • MERCEDES BENZ
    • 001 429 17 44
  • LOHR
    • A05021250
  • LEYLAND
    • EXABRB356
  • FAUN
    • 1614112

Description

What does a pressure limiting valve do?

This pressure limiting valve plays a critical role in the air brake system of heavy commercial vehicles by regulating air pressure levels. It operates using a high-strength internal mechanism designed to maintain stable pneumatic pressure within the system, ensuring reliable braking performance under heavy loads.

Vehicle and system compatibility

This component is compatible with Mercedes-Benz, Scania, Faun, Leyland, and Lohr vehicles. It is also designed to work with WABCO systems. The part features M22x1,5 ports and an inlet pressure of 7,5 BAR to ensure consistent operation across various heavy-duty applications.

Installation and maintenance

For proper installation, technicians should verify the adjustment range of 1,2 to 6,2 BAR and ensure all M22x1,5 connections are secure. Regular inspection of the valve is recommended to prevent pressure fluctuations in the braking or suspension circuits.

Selection guidance

Consult your authorized distributor to ensure correct fitment for your specific vehicle application.

OE cross-reference

301.07.0073 (Pressure Limiting Valve) is the equivalent of the Faun, Leyland, Lohr, Mercedes-Benz, Scania and WABCO OE numbers. This part directly replaces Faun OE number 1614112. It also replaces Leyland OE number EXABRB356, Lohr OE number A05021250, Mercedes-Benz OE number 0014291744, Scania OE number 2090277 and WABCO OE number 4750103090.

Technical Specifications

Technical Specifications
Port 1M22x1,5
Port 2M22x1,5
Inlet Pressure7,5 BAR
Adjustment Range1,2 …..6,2 BAR
Outlet Pressure5,7 BAR

Other OEMs

FAUN

  • 1614112

LEYLAND

  • EXABRB356

LOHR

  • A05021250

MERCEDES BENZ

  • A0014291744
  • 0014291744
  • 001 429 17 44

SCANIA

  • 2090277

WABCO

  • 4750103090
  • 475 010 309 0

Compatible Vehicles

Compatible Vehicles
BrandModelModel TypeEngine
FAUN
LEYLAND
LOHR
MERCEDES BENZ
SCANIA
WABCO

FAQ

What is the function of this pressure limiting valve?
It regulates air pressure within the braking or suspension system by venting excess air once a specific threshold is reached.
What are the port specifications for this valve?
This component features M22x1,5 ports with an inlet pressure rating of 7,5 BAR.
Which vehicle brands is this component compatible with?
It is compatible with Mercedes-Benz, Scania, Faun, Leyland, and Lohr vehicles.
What is the adjustment range for this part?
The valve provides an adjustable pressure range between 1,2 BAR and 6,2 BAR.
What are the OE reference numbers of this part?
301.07.0073 directly replaces Faun OE number 1614112. It also replaces Leyland OE number EXABRB356, Lohr OE number A05021250, Mercedes-Benz OE number 0014291744, Scania OE number 2090277 and WABCO OE number 4750103090.
