301.07.0064 Pressure Limiting Valve, Brake System

1593 Views Updated

301.07.0064 Compatible Pressure Limiting Valve — DAF Scania

301.07.0064

Summary

This pressure limiting valve is designed for heavy commercial vehicle air brake systems, specifically compatible with DAF and Scania. It features M22x1.5 ports, an inlet pressure of 12.4 BAR, and an adjustment range of 5.8 to 10.8 BAR to ensure precise braking performance. Equivalent to OE DAF 1506190, Scania 1356634 and WABCO 4750102000.

Product identifiers
EAN Code8683457011694
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Compatible OEM Codes

  • SCANIA
    • 1935016
    • 1356634
  • WABCO
    • 475 010 200 0
  • DAF
    • 1506190

Description

What does a pressure limiting valve do?

This pressure limiting valve plays a critical role in the pneumatic air brake system of heavy commercial vehicles. By regulating the air pressure within the braking circuit, it ensures that the braking force remains consistent and within safe operational limits, protecting the system from over-pressurization.

Vehicle compatibility and fitment

The component is engineered to be compatible with DAF and Scania trucks. It is designed to meet the rigorous demands of heavy-duty service, ensuring reliable performance in various driving conditions. This part is an essential replacement for maintaining optimal braking efficiency in these vehicle classes.

Technical specifications and installation

Technicians should note the technical specifications during installation to ensure proper fitment. The valve features M22x1.5 ports for both inlet and outlet, with an inlet pressure rating of 12.4 BAR and an adjustment range between 5.8 and 10.8 BAR. Regular inspection of the pneumatic lines and connections is recommended to prevent pressure drops.

Maintenance guidance

When replacing this component, ensure that the existing system pressure aligns with the 8 BAR outlet specification to maintain braking integrity.

OE cross-reference

301.07.0064 (Pressure Limiting Valve) is the equivalent of the DAF, Scania and WABCO OE numbers. This part directly replaces DAF OE number 1506190. It also replaces Scania OE numbers 1356634, 1935016 and WABCO OE number 4750102000.

Technical Specifications

Technical Specifications
Port 1M22x1,5
Port 2M22x1,5
Inlet Pressure12,4 BAR
Adjustment Range5,8 …..10,8 BAR
Outlet Pressure8 BAR

Other OEMs

DAF

  • 1506190

SCANIA

  • 1935016
  • 1356634

WABCO

  • 4750102000
  • 475 010 200 0

Compatible Vehicles

Compatible Vehicles
BrandModelModel TypeEngine
DAF
SCANIA
WABCO

FAQ

What is the function of this pressure limiting valve?
It regulates air pressure within the braking system to ensure stable and safe braking performance for heavy commercial vehicles.
Which vehicle brands is this part compatible with?
This component is designed for use in DAF and Scania trucks, as well as systems compatible with WABCO.
What are the technical port specifications?
The valve is equipped with M22x1.5 ports for both the inlet and the outlet to facilitate standard pneumatic connections.
What is the expected pressure adjustment range?
The unit operates with an inlet pressure of 12.4 BAR and provides an adjustment range between 5.8 and 10.8 BAR.
What are the OE reference numbers of this part?
301.07.0064 directly replaces DAF OE number 1506190. It also replaces Scania OE numbers 1356634, 1935016 and WABCO OE number 4750102000.
