301.07.0061 Pressure Limiting Valve WABCO Compatible
301.07.0061
Summary
This pressure limiting valve is engineered for heavy commercial vehicle brake systems. It features M16x1,5 ports, an inlet pressure of 8,5 BAR, and an adjustment range of 4,0 to 8,0 BAR to ensure precise pneumatic regulation. Equivalent to OE WABCO 4750155040.
| EAN Code | 8683457011663 |
|---|
Ready to Order
Compatible OEM Codes
-
WABCO
- 475 015 504 0
Description
This pressure limiting valve plays a critical role in maintaining stable pneumatic pressure within the braking system. By regulating the flow based on specific pressure thresholds, it ensures the stability and safety of the vehicle's pneumatic circuits during operation.
The component is designed to be compatible with WABCO systems. It operates with an inlet pressure of 8,5 BAR and provides a precise outlet pressure of 7,3 BAR. The adjustment range is set between 4,0 and 8,0 BAR, ensuring reliable performance under heavy-duty conditions.
For proper installation and maintenance, technicians should verify the M16x1,5 port connections and ensure all lines are free of contaminants. Regular inspections of the safety pressure threshold at 9,8 BAR are recommended to maintain optimal system integrity.
Check the compatibility list.
The component is designed to be compatible with WABCO systems. It operates with an inlet pressure of 8,5 BAR and provides a precise outlet pressure of 7,3 BAR. The adjustment range is set between 4,0 and 8,0 BAR, ensuring reliable performance under heavy-duty conditions.
For proper installation and maintenance, technicians should verify the M16x1,5 port connections and ensure all lines are free of contaminants. Regular inspections of the safety pressure threshold at 9,8 BAR are recommended to maintain optimal system integrity.
Check the compatibility list.
OE cross-reference
301.07.0061 (Pressure Limiting Valve) is the equivalent of the WABCO OE number. This part directly replaces WABCO OE number 4750155040.Technical Specifications
| Port 1 | M16x1,5 |
|---|---|
| Port 2 | M16x1,5 |
| Inlet Pressure | 8,5 BAR |
| Adjustment Range | 4,0 …..8,0 BAR |
| Outlet Pressure | 7,3 BAR |
| Safety Pressure | 9,8 BAR |
Other OEMs
WABCO
- 4750155040
- 475 015 504 0
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| WABCO |
FAQ
What is the function of this pressure limiting valve?
It regulates pneumatic pressure within the brake system to ensure consistent performance and prevents over-pressurization by maintaining specific outlet levels.
What are the port specifications for this component?
This valve features two M16x1,5 ports designed for secure pneumatic connections in heavy commercial vehicle systems.
What is the adjustment range for this valve?
The device provides a precise adjustment range from 4,0 BAR to 8,0 BAR to meet specific braking requirements.
How can I ensure compatibility with my system?
Check the compatibility list or consult your authorized distributor to verify if this matches your current WABCO system requirements.
What are the OE reference numbers of this part?
301.07.0061 directly replaces WABCO OE number 4750155040.
