301.07.0059 Pressure Limiting Valve WABCO compatible
301.07.0059
Summary
This pressure limiting valve is engineered for heavy commercial vehicle brake systems. It features M16x1,5 ports, an adjustment range of 4.0 to 8.0 BAR, and a safety pressure of 8.5 BAR to ensure precise pneumatic control in demanding environments. Equivalent to OE WABCO 4750155010.
| EAN Code | 8683457011649 |
|---|
Ready to Order
Compatible OEM Codes
-
WABCO
- 475 015 501 0
Description
What does a pressure limiting valve do?
This pressure limiting valve plays a critical role in regulating pneumatic pressure within heavy commercial vehicle brake systems. By controlling the flow and maintaining specific pressure levels, it ensures the stability and reliability of the braking performance under various load conditions.Compatibility and performance
The component is compatible with WABCO systems and provides precise regulation with an outlet pressure of 6.0 BAR. This valve is designed for heavy-duty applications, utilizing high-strength components to withstand constant pneumatic fluctuations.Installation and maintenance
For proper installation, technicians should verify the M16x1,5 port connections and ensure the adjustment range is set correctly between 4.0 and 8.0 BAR. Regular inspections of the seals and connection points are recommended to maintain optimal system integrity.System troubleshooting
Consult your authorized distributor to check the compatibility list for your specific vehicle application.OE cross-reference
301.07.0059 (Pressure Limiting Valve) is the equivalent of the WABCO OE number. This part directly replaces WABCO OE number 4750155010.Technical Specifications
| Port 1 | M16x1,5 |
|---|---|
| Port 2 | M16x1,5 |
| Inlet Pressure | 8,5 BAR |
| Adjustment Range | 4,0 …..8,0 BAR |
| Outlet Pressure | 6,0 BAR |
| Safety Pressure | 8,5 BAR |
Other OEMs
WABCO
- 4750155010
- 475 015 501 0
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| WABCO |
FAQ
What is the function of this pressure limiting valve?
It regulates air pressure within the brake system to ensure the braking force remains within safe operational limits.
What are the port specifications for this component?
This valve is equipped with M16x1,5 ports on both sides to facilitate standard pneumatic connections.
What is the safety pressure rating?
The unit features a safety pressure threshold of 8.5 BAR to protect the pneumatic circuit from over-pressurization.
Is this valve compatible with WABCO systems?
Yes, this component is designed to be compatible with WABCO systems and follows their technical requirements.
What are the OE reference numbers of this part?
301.07.0059 directly replaces WABCO OE number 4750155010.
