301.07.0048 Pressure Limiting Valve for DAF and Scania
301.07.0048
Summary
This pressure limiting valve is engineered for heavy commercial vehicle air brake systems. It features M16x1.5 ports, an 11 BAR inlet pressure, and an outlet pressure of 7.5 BAR ± 0.2 BAR, ensuring precise pneumatic regulation for Scania, DAF, and Iveco applications. Equivalent to OE DAF 1505096, Iveco 4780200 and Kässbohrer 20199000623.
| EAN Code | 8683457011533 |
|---|
Ready to Order
Compatible OEM Codes
-
IVECO
- 4780202
- 4780201
- 4780200
-
WABCO
- 475 015 031 0
-
SCANIA
- 2090288
-
KASSBOHRER
- 20199000623
-
DAF
- 1505096
Description
This pressure limiting valve plays a critical role in maintaining regulated air pressure within the pneumatic braking system of heavy commercial vehicles. By utilizing a precision piston-and-spring mechanism, it manages air flow to ensure consistent system performance under heavy-duty operating conditions.
This component is designed to be compatible with Scania, DAF, Iveco, and Kässbohrer vehicles. It works effectively within complex air brake architectures and is also suitable for various heavy commercial vehicle applications that require precise pressure thresholds.
Installation requires careful attention to the M16x1.5 port connections to ensure a leak-free fitment. Technicians should verify that the system inlet pressure reaches the required 11 BAR to allow the valve to function within its specified adjustment range of 4.0 to 8.0 BAR.
Regular inspection of the valve helps prevent pressure fluctuations in the braking circuit. Maintaining these components ensures the safety and reliability of the vehicle's pneumatic systems during long-haul operations.
Check the compatibility list.
This component is designed to be compatible with Scania, DAF, Iveco, and Kässbohrer vehicles. It works effectively within complex air brake architectures and is also suitable for various heavy commercial vehicle applications that require precise pressure thresholds.
Installation requires careful attention to the M16x1.5 port connections to ensure a leak-free fitment. Technicians should verify that the system inlet pressure reaches the required 11 BAR to allow the valve to function within its specified adjustment range of 4.0 to 8.0 BAR.
Regular inspection of the valve helps prevent pressure fluctuations in the braking circuit. Maintaining these components ensures the safety and reliability of the vehicle's pneumatic systems during long-haul operations.
Check the compatibility list.
OE cross-reference
301.07.0048 (Pressure Limiting Valve) is the equivalent of the DAF, Iveco, Kässbohrer, Scania and WABCO OE numbers. This part directly replaces DAF OE number 1505096. It also replaces Iveco OE numbers 4780200, 4780201, 4780202, Kässbohrer OE number 20199000623, Scania OE number 2090288 and WABCO OE number 4750150310.Technical Specifications
| Port 1 | M16x1,5 |
|---|---|
| Port 2 | M16x1,5 |
| Inlet Pressure | 11 BAR |
| Adjustment Range | 4,0 …..8,0 BAR |
| Outlet Pressure | 7,5 BAR ± 0,2 BAR |
| Safety Pressure | 10,0 BAR |
Other OEMs
DAF
- 1505096
IVECO
- 4780202
- 4780201
- 4780200
KASSBOHRER
- 20199000623
SCANIA
- 2090288
WABCO
- 4750150310
- 475 015 031 0
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| DAF | |||
| IVECO | |||
| KASSBOHRER | |||
| SCANIA | |||
| WABCO |
FAQ
What is the function of this pressure limiting valve?
It regulates air pressure within the braking system by opening at a specific threshold to vent excess air, ensuring stable pneumatic operation.
Which vehicle brands is this part compatible with?
This component is compatible with DAF, Iveco, Kässbohrer, and Scania vehicles, as well as various WABCO systems.
What are the technical specifications for this valve?
The valve features M16x1.5 ports, an 11 BAR inlet pressure, an outlet pressure of 7.5 BAR ± 0.2 BAR, and a safety pressure of 10.0 BAR.
How do I know if my pressure limiting valve needs replacement?
Technicians should look for signs of inconsistent braking performance or unexpected air pressure drops in the pneumatic circuit.
What are the OE reference numbers of this part?
301.07.0048 directly replaces DAF OE number 1505096. It also replaces Iveco OE numbers 4780200, 4780201, 4780202, Kässbohrer OE number 20199000623, Scania OE number 2090288 and WABCO OE number 4750150310.
