301.07.0034 Pressure Limiting Valve, Brake System

2227 Views Updated

301.07.0034 Compatible Pressure Limiting Valve — Scania

301.07.0034

Summary

This pressure limiting valve is designed for heavy commercial vehicle brake systems, featuring M22x1.5 VOSS ports, an 8 BAR inlet pressure, and an adjustment range of 0.2 to 2.0 BAR. It ensures precise pressure regulation for reliable braking performance in demanding environments. Equivalent to OE Kögel 335703, Langendorf 1111702 and Liebherr 11082472.

Product identifiers
EAN Code8683457011397
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Compatible OEM Codes

  • WABCO
    • 475 010 324 0
  • SCANIA
    • 2090281
  • NOOTEBOOM
    • 2075785
  • MERCEDES BENZ
    • 003 431 51 06
  • LIEBHERR
    • 11082472
  • LANGENDORF
    • 1111702
  • KÖGEL
    • 335703

Description

What does a pressure limiting valve do?

This pressure limiting valve plays a critical role in the pneumatic brake system of heavy commercial vehicles by regulating air pressure to prevent system overpressure. Built with high-strength components, it ensures consistent braking force and protects downstream components from excessive pressure fluctuations.

Compatible vehicles and systems

This component is compatible with Mercedes-Benz, Scania, Kögel, Langendorf, Liebherr, and Nooteboom vehicles. It is also designed to work seamlessly with WABCO systems to maintain optimal pneumatic stability across the brake circuit.

Installation and maintenance

For correct installation, technicians should verify that the M22x1.5 VOSS ports are free of debris and that the 8 BAR inlet pressure aligns with the vehicle's pneumatic requirements. Maintaining the adjustment range between 0.2 and 2.0 BAR is essential for the safety and efficiency of the braking system.

Troubleshooting and selection

Regular inspections of the valve seating and port connections can prevent air leaks and ensure long-term reliability in heavy-duty service conditions.

OE cross-reference

301.07.0034 (Pressure Limiting Valve) is the equivalent of the Kögel, Langendorf, Liebherr, Mercedes-Benz, Nooteboom, Scania and WABCO OE numbers. This part directly replaces Kögel OE number 335703. It also replaces Langendorf OE number 1111702, Liebherr OE number 11082472, Mercedes-Benz OE number 0034315106, Nooteboom OE number 2075785, Scania OE number 2090281 and WABCO OE number 4750103240.

Technical Specifications

Technical Specifications
Port 1M22x1,5 VOSS
Port 2M22x1,5 VOSS
Inlet Pressure8 BAR
Adjustment Range0,2 …..2,0 BAR
Outlet Pressure1,4 BAR

Other OEMs

KÖGEL

  • 335703

LANGENDORF

  • 1111702

LIEBHERR

  • 11082472

MERCEDES BENZ

  • A0034315106
  • 0034315106
  • 003 431 51 06

NOOTEBOOM

  • 2075785

SCANIA

  • 2090281

WABCO

  • 4750103240
  • 475 010 324 0

Compatible Vehicles

Compatible Vehicles
BrandModelModel TypeEngine
KÖGEL
LANGENDORF
LIEBHERR
MERCEDES BENZ
NOOTEBOOM
SCANIA
WABCO

FAQ

What is the function of this pressure limiting valve?
It regulates the air pressure within the braking system to ensure that downstream components receive a controlled amount of pressure, typically maintaining an outlet pressure around 1.4 BAR.
Which vehicle makes are compatible with this part?
This valve is suitable for Mercedes-Benz, Scania, Kögel, Langendorf, Liebherr, and Nooteboom heavy commercial vehicles.
What are the technical port specifications?
The unit features two M22x1.5 VOSS ports and is designed to operate with an inlet pressure of 8 BAR.
How can I identify if the valve needs replacement?
Technicians should look for signs of air leaks at the M22x1.5 ports or inconsistent braking response that suggests the 0.2 to 2.0 BAR adjustment range is no longer stable.
What are the OE reference numbers of this part?
301.07.0034 directly replaces Kögel OE number 335703. It also replaces Langendorf OE number 1111702, Liebherr OE number 11082472, Mercedes-Benz OE number 0034315106, Nooteboom OE number 2075785, Scania OE number 2090281 and WABCO OE number 4750103240.
