301.02.0123 Air Dryer Valve for Iveco Trucks
301.02.0123
Summary
This high-strength air dryer valve is designed for Iveco heavy commercial vehicles. It features a 24V heater, 11 BAR pressure rating, and multiple M22x1.5 and M16x1.5 ports to ensure reliable air processing in demanding environments. Equivalent to OE WABCO 4324160010.
| EAN Code | 8683457012684 |
|---|
Ready to Order
Compatible OEM Codes
-
WABCO
- 432 416 001 0
Description
What does an air dryer valve do?
This air dryer valve plays a critical role in the pneumatic brake system by removing moisture, oil, and particulates from the compressed air supply. By ensuring a continuous flow of dry air, it protects downstream components from corrosion and freezing, maintaining the integrity of the entire braking circuit.Compatibility and technical specifications
Specifically engineered for Iveco trucks, this component operates effectively under 11 BAR pressure. It includes a 24V heater to prevent moisture buildup in cold climates and features various port configurations including M22x1.5 and M16x1.5 to ensure precise integration into the vehicle's air management system.Installation and maintenance guidance
For professional technicians and fleet managers, regular inspection of the valve ports and electrical connections is essential. Maintaining correct port seating for M22x1.5 and M16x1.5 threads ensures leak-free operation. Consult your authorized distributor to ensure exact fitment for your specific chassis requirements.System reliability
This component is a high-quality replacement for WABCO systems, providing reliable performance for heavy commercial vehicle brake systems.OE cross-reference
301.02.0123 (Air Dryer Valve Air Dryer Valves) is the equivalent of the WABCO OE number. This part directly replaces WABCO OE number 4324160010.Technical Specifications
| Heater | 24 V |
|---|---|
| Port 1 | M22x1,5 |
| Port 4 | M16x1,5 |
| Port 12 | M22x1,5 |
| Port 21 | M22x1,5 |
| Pressure | 11 BAR |
| Port 25 | M22x1,5 |
| Port 26 | M22x1,5 |
| Port 25 | M16x1,5 |
| Port 3 | - |
Other OEMs
WABCO
- 4324160010
- 432 416 001 0
Related Products
Repair Kits
Used In
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| IVECO | |||
| WABCO |
FAQ
What is the function of this air dryer valve?
It removes water, oil, and contaminants from the compressed air to protect the braking system from damage.
Does this valve include a heater?
Yes, this unit is equipped with a 24V heater to prevent moisture freezing in the lines.
What are the port specifications for this component?
The unit features several connection points, including M22x1.5 and M16x1.5 ports, suitable for high-pressure applications.
Is this compatible with Iveco vehicles?
Yes, this part is specifically designed to be compatible with Iveco heavy commercial vehicle systems.
What are the OE reference numbers of this part?
301.02.0123 directly replaces WABCO OE number 4324160010.
