2900 030 001 Single Cylinder, Air Compressor
2948 Visualized

2900 030 001 ATLAS COPCO CUMMINS Single Cylinder, Air Compressor

2900 030 001

Summary

●Cylinder Bore: Ø80.00 ●Stroke: 45mm ●Swept Volume: 225cm³ ●Air Inlet Port: M26x1,5 ●Air Outlet Port: M22x1,5 ●Number of Cylinders: 1 ●Through Drive: OK ●Air Unloader Port: M10x1 ●Water (W) or Air (A) Cooled: W ●Water Inlet Port: M16x1,5 ●Water Outlet Port: M16x1,5 ●With ESS Feature: OK ●Weight: 10,6 KG

EAN Code8699031071206
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Description

This single cylinder air compressor is engineered to provide consistent pneumatic pressure within the heavy commercial vehicle braking system. Designed for high-duty cycles, the component features a robust construction to ensure long-term operational stability in demanding environments. The technical architecture includes a water-cooled system with specific port dimensions to manage thermal loads effectively during operation.

2900 030 001 is the OE-equivalent single cylinder air compressor used in ATLAS COPCO 4812316400, CUMMINS 3965888, CUMMINS 4937720, KNORR-BREMSE K001389, KNORR-BREMSE LK3863, and VOLKSWAGEN TRUCK 2R0 101 759B systems. This component is specifically designed for heavy commercial vehicle applications including various models of VOLKSWAGEN TRUCK and CUMMINS ISB engines.

For workshop technicians performing maintenance or replacement, this part ensures seamless integration with existing engine assemblies. The unit features an M26x1,5 air inlet port and an M22x1,5 air outlet port to meet standard assembly requirements. Proper inspection of the water inlet and outlet ports (M16x1,5) is recommended during installation to maintain optimal cooling efficiency and prevent system overheating.

Technical Specifications

Cylinder BoreØ80.00
Stroke45mm
Swept Volume225cm³
Air Inlet PortM26x1,5
Air Outlet PortM22x1,5
Number of Cylinders1
Through DriveOK
Air Unloader PortM10x1
Water (W) or Air (A) CooledW
Water Inlet PortM16x1,5
Water Outlet PortM16x1,5
With ESS FeatureOK
Water Cooled Valve PlateOK
Weight10,6 KG

Other OEMs

ATLAS COPCO

CUMMINS

KNORR-BREMSE

VOLKSWAGEN TRUCK

Related Products

Repair Kits

Vehicles Used

BrandModelEngine
ATLAS COPCO
CUMMINS ISB
KNORR-BREMSE
VOLKSWAGEN TRUCK 13.170
VOLKSWAGEN TRUCK 15.170
VOLKSWAGEN TRUCK 15.190
VOLKSWAGEN TRUCK 17.250
VOLKSWAGEN TRUCK 17.260
VOLKSWAGEN TRUCK 23.250
VOLKSWAGEN TRUCK 8.150
VOLKSWAGEN TRUCK 9.150
VOLKSWAGEN TRUCK 9.160

FAQ

Which OEM numbers is this part compatible with?
This part is compatible with ATLAS COPCO 481231640{...}, CUMMINS 3965888, CUMMINS 4937720, KNORR-BREMSE K001389, KNORR-BREMSE LK3863, and VOLKSWAGEN TRUCK 2R0 10... {etc}.
What are the main technical specifications of this compressor?
The unit features a Ø80.0 much bore, a 45mm stroke, and a swept volume of 225cm³. It utilizes a water-cooling system for stable performance.
Is this component suitable for heavy commercial vehicles?
Yes, it is specifically designed for heavy commercial vehicle systems, including compatible models from VOLKSWAGEN TRUCK and CUMMINS.
Does this air compressor include an ESS feature?
Yes, the product includes the ESS feature as specified in the technical documentation for reliable pneumatic control.
What are the port dimensions for installation?
The air inlet port is M26x1,5 and the air outlet port is M22x1,5. Water ports are both M16x1,5.
