1900 160 001 BMC Compatible Air Compressor
1900 160 001
Summary
This single cylinder air compressor is designed for heavy commercial vehicle air brake systems. It features a Ø80.00 mm cylinder bore, a 45 mm stroke, and a 225cm³ swept volume. This water-cooled component ensures reliable performance in demanding environments. Compatible with BMC vehicles and Knorr-Bremse systems. Equivalent to OE BMC 9P920586 and Knorr-Bremse K008457.
| EAN Code | 8699031059600 |
|---|
Ready to Order
Compatible OEM Codes
-
KNORR-BREMSE
- LK3875
- K008457
-
BMC
- 9P920586
Description
What does an air compressor do?
This air compressor serves as a critical component within the pneumatic braking system, ensuring consistent air pressure for heavy commercial vehicle operations. Built with high-strength components, this single cylinder unit is engineered to withstand high-pressure cycles and extreme thermal loads during continuous service.Compatible vehicles and systems
This specific model is compatible with BMC vehicles and is designed to meet the requirements of Knorr-Bremse systems. It is also fitted to BMC trucks. The unit features a water-cooled design to manage operating temperatures effectively during long-haul transport.Installation and maintenance
For proper installation, technicians should verify the M26x1,5 air inlet port and M18x1,5 air outlet port connections. The water inlet and outlet ports utilize M16x1,5 threads. Regular inspection of the through drive mechanism and cooling lines is recommended to maintain optimal system pressure.Operational reliability
Maintaining correct oil levels and checking for leaks at the port interfaces ensures the longevity of the internal piston movement and prevents premature wear of the cylinder assembly.OE cross-reference
1900 160 001 (Sprężarka jednocylindrowa Air Compressor) is the equivalent of the BMC and Knorr-Bremse OE numbers. This part directly replaces BMC OE number 9P920586. It also replaces Knorr-Bremse OE numbers K008457, LK3875.Technical Specifications
| Cylinder Bore | Ø80.00 |
|---|---|
| Stroke | 45 mm |
| Swept Volume | 225cm³ |
| Air Inlet Port | M26x1,5 |
| Air Outlet Port | M18x1,5 |
| Number of Cylinders | 1 |
| Through Drive | OK |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | M16x1,5 |
| Water Outlet Port | M16x1,5 |
| Weight | 11,5 KG |
Other OEMs
BMC
- 9P920586
KNORR-BREMSE
- LK3875
- K008457
Related Products
Repair Kits
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| BMC | |||
| KNORR-BREMSE |
FAQ
What is the primary function of this compressor?
This single cylinder air compressor generates the necessary compressed air required for the vehicle's pneumatic braking system to operate safely.
Which vehicle brands are compatible with this part?
This component is specifically designed for use in BMC vehicles and is compatible with Knorr-Bremse systems.
What are the key technical specifications?
The unit features a Ø80.00 mm cylinder bore, a 45 mm stroke, a 225cm³ swept volume, and a water-cooled configuration.
How should I check for proper installation?
Technicians should ensure that the M26x1,5 inlet and M18x1,5 outlet ports are correctly sealed and that the water cooling lines are unobstructed.
What are the OE reference numbers of this part?
1900 160 001 directly replaces BMC OE number 9P920586. It also replaces Knorr-Bremse OE numbers K008457, LK3875.
