1700 040 002 Single Cylinder Air Compressor for Renault Trucks
1700 040 002
Summary
This water-cooled single cylinder air compressor is engineered for Renault Trucks. It features a Ø78.00 mm cylinder bore, a 52 mm stroke, and M26x1.5 air ports, providing reliable air compression for heavy commercial vehicle brake systems. Equivalent to OE Knorr-Bremse LP3861 and Renault Trucks 5000691934.
| EAN Code | 8699031059907 |
|---|
Ready to Order
Compatible OEM Codes
-
RENAULT TRUCKS
- 7485003208
- 5001857409
- 5000691934
-
KNORR-BREMSE
- SEB01152X00
- LP3861
Description
This single cylinder air compressor is a critical component within the pneumatic braking system of heavy commercial vehicles. It functions by compressing intake air and delivering it to the air processing unit, ensuring consistent pressure for the entire brake circuit. Designed with heavy-duty grade materials, this unit provides the necessary reliability for demanding workshop environments.
This specific model is compatible with Renault Trucks engines and systems. It features a water-cooled design with a water inlet port of M18x1.5 and an outlet port of M18x1.5, ensuring optimal thermal management during high-load operations. The unit provides a swept volume of 248cm³ to maintain system stability.
For proper installation, technicians should verify that all M26x1.5 air ports and M18x1.5 water ports are seated correctly to prevent leaks. Regular inspection of the through drive mechanism and valve plate integrity is recommended to maintain peak pneumatic performance in the vehicle's braking system.
Consult your authorized distributor for more information on fitment and technical support.
This specific model is compatible with Renault Trucks engines and systems. It features a water-cooled design with a water inlet port of M18x1.5 and an outlet port of M18x1.5, ensuring optimal thermal management during high-load operations. The unit provides a swept volume of 248cm³ to maintain system stability.
For proper installation, technicians should verify that all M26x1.5 air ports and M18x1.5 water ports are seated correctly to prevent leaks. Regular inspection of the through drive mechanism and valve plate integrity is recommended to maintain peak pneumatic performance in the vehicle's braking system.
Consult your authorized distributor for more information on fitment and technical support.
OE cross-reference
1700 040 002 (Single Cylinder Compressor) is the equivalent of the Knorr-Bremse and Renault Trucks OE numbers. This part directly replaces Knorr-Bremse OE numbers LP3861, SEB01152X00. It also replaces Renault Trucks OE numbers 5000691934, 5001857409, 7485003208.Technical Specifications
| Cylinder Bore | Ø78.00 |
|---|---|
| Stroke | 52 mm |
| Swept Volume | 248cm³ |
| Air Inlet Port | M26x1,5 |
| Air Outlet Port | M26x1,5 |
| Number of Cylinders | 1 |
| Through Drive | OK |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | M18x1,5 |
| Water Outlet Port | M18x1,5 |
| Water Cooled Valve Plate | OK |
| Weight | 12,9 KG |
Other OEMs
KNORR-BREMSE
- SEB01152X00
- LP3861
RENAULT TRUCKS
- 7485003208
- 5001857409
- 5000691934
Related Products
Repair Kits
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| KNORR-BREMSE | |||
| RENAULT TRUCKS |
FAQ
How does this compressor support the braking system?
The compressor compresses intake air and sends it to the air processing unit and tanks, acting as the primary source of pressure for the vehicle's pneumatic brakes.
What are the cooling specifications for this unit?
This is a water-cooled model featuring M18x1.5 water inlet and outlet ports to ensure stable operating temperatures under heavy loads.
Which vehicle makes is this compatible with?
This component is designed for compatibility with Renault Trucks heavy commercial vehicles.
What technical dimensions define this compressor?
It features a Ø78.00 mm cylinder bore, a 52 mm stroke, and provides a swept volume of 248cm³.
What are the OE reference numbers of this part?
1700 040 002 directly replaces Knorr-Bremse OE numbers LP3861, SEB01152X00. It also replaces Renault Trucks OE numbers 5000691934, 5001857409, 7485003208.
