1600 060 002 DAF Compatible Twin Cylinder Air Compressor
1600 060 002
Summary
This heavy-duty twin cylinder air compressor is designed for DAF XF95, CF85, and F95 series. Featuring a Ø75.00 mm cylinder bore, 50 mm stroke, and water-cooled design, it ensures efficient air delivery for heavy commercial vehicle braking systems. Equivalent to OE DAF 1604420 and WABCO 9115045040.
| EAN Code | 8699031047720 |
|---|
Ready to Order
Compatible OEM Codes
-
DAF
- 1628444R
- 1628444A
- 1628444
- 1604420R
- 1604420A
- 1604420
-
WABCO
- 911 504 505 0
- 911 504 504 0
Description
What does a twin cylinder compressor do?
This twin cylinder compressor is an essential engine-driven component within the air brake system of heavy commercial vehicles. By utilizing two piston-cylinder assemblies, it generates a higher volume of compressed air compared to single-cylinder units, ensuring rapid reservoir replenishment. This specific model features a Ø75.00 mm cylinder bore and a 50 mm stroke to provide reliable performance under demanding service conditions.Vehicle and system compatibility
Designed specifically for DAF vehicles, including the XF95, 95XF, CF85, CF85 II, 75CF, F75, and F95 models. This unit is engineered to meet the high air demand requirements of multi-axle tractor units and heavy-duty trucks. It is also compatible with WABCO systems to ensure seamless integration into existing pneumatic architectures.Technical specifications and installation
The unit is a water-cooled design featuring M14x1,5 water inlet and outlet ports, alongside M26x1,5 air inlet and outlet ports. For efficient installation and maintenance, technicians should verify the through drive configuration and check the M12x1,5 unloader port connections. The assembly includes a water-cooled valve plate and ESS feature for enhanced operational stability.Maintenance guidance
To ensure optimal system longevity, regular inspection of the water cooling lines and air ports is recommended. Proper mounting according to the vehicle's original specifications prevents premature wear of the internal piston assemblies.OE cross-reference
1600 060 002 (Twin Cylinder Compressor) is the equivalent of the DAF and WABCO OE numbers. This part directly replaces DAF OE numbers 1604420, 1604420A, 1604420R, 1628444, 1628444A, 1628444R. It also replaces WABCO OE numbers 9115045040, 9115045050.Technical Specifications
| Cylinder Bore | Ø75.00 |
|---|---|
| Stroke | 50 mm |
| Swept Volume | 442cm³ |
| Air Inlet Port | M26x1,5 |
| Air Outlet Port | M26x1,5 |
| Number of Cylinders | 2 |
| Through Drive | OK |
| Air Unloader Port | M12x1,5 |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | M14x1,5 |
| Water Outlet Port | M14x1,5 |
| With ESS Feature | OK |
| Water Cooled Valve Plate | OK |
| Weight | 19,4 KG |
Other OEMs
DAF
- 1628444R
- 1628444A
- 1628444
- 1604420R
- 1604420A
- 1604420
WABCO
- 9115045050
- 9115045040
- 911.504.505.0
- 911.504.504.0
- 911 504 505 0
- 911 504 504 0
Related Products
Repair Kits
Similar Products
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| DAF | |||
| DAF | 75CF | ||
| DAF | 85CF | ||
| DAF | 95XF | ||
| DAF | CF85 | ||
| DAF | CF85 II | ||
| DAF | F75 | ||
| DAF | F95 | ||
| DAF | XF95 | ||
| WABCO |
FAQ
What is the benefit of a twin cylinder design?
A twin cylinder compressor produces two compression strokes per crankshaft revolution. This delivers higher air output at the same engine speed than single-cylinder models, allowing for faster reservoir filling.
Which DAF models is this compressor compatible with?
This unit is designed for DAF XF95, 95XF, CF85, CF85 II, 75CF, F75, and F95 models to ensure reliable braking performance.
Is this a water-cooled or air-cooled unit?
This specific model is a water-cooled unit featuring M14x1,5 water inlet and outlet ports to manage operating temperatures effectively.
What are the key technical dimensions?
The compressor features a Ø75.00 mm cylinder bore, a 50 mm stroke, and a swept volume of 442cm³, providing robust pneumatic capacity.
What are the OE reference numbers of this part?
1600 060 002 directly replaces DAF OE numbers 1604420, 1604420A, 1604420R, 1628444, 1628444A, 1628444R. It also replaces WABCO OE numbers 9115045040, 9115045050.
