1500 160 002 Compatible Twin Cylinder Compressor
1500 160 002
Summary
This water-cooled twin cylinder air compressor features a Ø86.00 mm cylinder bore, 40mm stroke, and 460cm³ swept volume. Designed for heavy-duty performance, it includes an M26x1.5 air outlet port and an ESS feature for efficient air brake system operation in Iveco vehicles. Equivalent to OE Iveco 504308843 and Knorr-Bremse K022249N00.
| EAN Code | 8699031050942 |
|---|
Ready to Order
Compatible OEM Codes
-
KNORR-BREMSE
- LP4857
- K022249N00
-
IVECO
- 504308843
Description
What does a twin cylinder compressor do?
This twin cylinder air compressor is a critical engine-driven component within the air brake system of heavy commercial vehicles, providing the necessary compressed air through two piston-cylinder assemblies. Designed with high-strength components, it ensures reliable pressure delivery for demanding braking operations. This water-cooled unit features a Ø86.00 mm bore and a 460cm³ swept volume to maintain consistent system performance.Vehicle and system compatibility
This specific unit is compatible with Iveco vehicles and meets the requirements of Knorr-Bremse systems. It is engineered to provide higher air output than single-cylinder alternatives, making it suitable for heavy-duty applications requiring rapid reservoir inflation. The assembly includes an ESS feature and a water-cooled valve plate to manage thermal loads effectively during continuous operation.Installation and maintenance
For correct installation, technicians should verify the M26x1.5 air inlet and outlet ports along with the M18x1.5 water ports. This through-drive compressor weighs 18.7 kg and requires proper coolant circulation to maintain its thermal stability. Ensuring all connections are secure prevents pressure drops within the pneumatic circuit.System performance
Consult your authorized distributor to check the compatibility list.OE cross-reference
1500 160 002 (Twin Cylinder Compressor) is the equivalent of the Iveco and Knorr-Bremse OE numbers. This part directly replaces Iveco OE number 504308843. It also replaces Knorr-Bremse OE numbers K022249N00, LP4857.Technical Specifications
| Cylinder Bore | Ø86.00 |
|---|---|
| Stroke | 40mm |
| Swept Volume | 460cm³ |
| Air Inlet Port | M26x1,5 |
| Air Outlet Port | M26x1,5 |
| Number of Cylinders | 2 |
| Through Drive | OK |
| Air Unloader Port | M12x1,5 |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | M18x1,5 |
| Water Outlet Port | M18x1,5 |
| With ESS Feature | OK |
| Water Cooled Valve Plate | OK |
| Weight | 18,7 KG |
Other OEMs
IVECO
- 504308843
KNORR-BREMSE
- LP4857
- K022249N00
Related Products
Repair Kits
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| IVECO | |||
| KNORR-BREMSE |
FAQ
What is the function of this twin cylinder compressor?
It acts as an engine-driven unit that generates compressed air using two piston-cylinder assemblies to provide high air output for heavy commercial vehicle braking systems.
Which vehicle makes is this compressor compatible with?
This component is designed to be compatible with Iveco vehicles and meets the technical standards required by Knorr-Bremse systems.
What are the technical specifications regarding its cooling?
This is a water-cooled unit featuring a water inlet and outlet port size of M18x1.5 to manage operating temperatures during use.
How can I identify if this is the correct replacement?
Check the bore size of Ø86.00 mm, the 460cm³ swept volume, and ensure the port sizes match your current installation requirements.
What are the OE reference numbers of this part?
1500 160 002 directly replaces Iveco OE number 504308843. It also replaces Knorr-Bremse OE numbers K022249N00, LP4857.
