1500 075 002 Iveco Compatible Twin Cylinder Compressor
1500 075 002
Summary
This water-cooled twin cylinder compressor is designed for heavy commercial vehicles, featuring a Ø86.00 mm cylinder bore, 40 mm stroke, and an air outlet port of M26x1,5. It provides high-capacity air production for demanding brake systems. Equivalent to OE Iveco 41211121 and Knorr-Bremse 1194194.
| EAN Code | 8699031050669 |
|---|
Ready to Order
Compatible OEM Codes
-
IVECO
- 99471918
- 41211425
- 41211339
- 41211121
-
KNORR-BREMSE
- LP4857
- 1194410
- 1194194
Description
What does a twin cylinder compressor do?
This twin cylinder compressor serves as a critical component within the air brake system, utilizing two piston-cylinder assemblies to generate a high volume of compressed air. Designed with heavy-duty grade materials, it ensures reliable performance and rapid reservoir filling for heavy commercial vehicles under demanding operational conditions.Vehicle compatibility and technical features
This unit is compatible with Iveco vehicles and is designed to meet the requirements of Knorr-Bremse systems. It features a water-cooled design with a water inlet and outlet port of M18x1,5, providing efficient thermal management during continuous operation. The assembly includes an integrated ESS feature and a water-cooled valve plate for enhanced durability.Installation and maintenance guidance
For professional installation, technicians should verify the M26x1,5 air inlet and outlet ports and the M12x1,5 unloader port specifications. Ensuring proper coolant flow through the M18x1,5 ports is essential for maintaining optimal operating temperatures and preventing premature wear in the piston assembly.Selection guidance
Consult your authorized distributor to confirm exact fitment and mounting requirements for your specific vehicle application.OE cross-reference
1500 075 002 (Twin Cylinder Compressor) is the equivalent of the Iveco and Knorr-Bremse OE numbers. This part directly replaces Iveco OE numbers 41211121, 41211339, 41211425, 99471918. It also replaces Knorr-Bremse OE numbers 1194194, 1194410, LP4857.Technical Specifications
| Cylinder Bore | Ø86.00 |
|---|---|
| Stroke | 40mm |
| Swept Volume | 460cm³ |
| Air Inlet Port | M26x1,5 |
| Air Outlet Port | M26x1,5 |
| Number of Cylinders | 2 |
| Through Drive | OK |
| Air Unloader Port | M12x1,5 |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | M18x1,5 |
| Water Outlet Port | M18x1,5 |
| With ESS Feature | OK |
| Water Cooled Valve Plate | OK |
| Weight | 18,7 KG |
Other OEMs
IVECO
- 99471918
- 41211425
- 41211339
- 41211121
KNORR-BREMSE
- LP4857
- 1194410
- 1194194
Related Products
Repair Kits
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| IVECO | |||
| KNORR-BREMSE |
FAQ
What is the function of a twin cylinder compressor?
It is an engine-driven unit that uses two piston assemblies to provide higher air output than single-cylinder types, ensuring faster reservoir filling in heavy commercial vehicles.
Is this compressor suitable for Iveco vehicles?
Yes, this specific twin cylinder model is designed to be compatible with Iveco vehicles and works effectively within Knorr-Bremse systems.
What are the key technical specifications of this unit?
The unit features a Ø86.00 mm bore, a 40mm stroke, a 460cm³ swept volume, and utilizes M26x1,5 ports for air inlet and outlet.
How does the cooling system work on this model?
This is a water-cooled unit that utilizes M18x1,5 inlet and outlet ports to manage thermal loads during high-demand air production.
What are the OE reference numbers of this part?
1500 075 002 directly replaces Iveco OE numbers 41211121, 41211339, 41211425, 99471918. It also replaces Knorr-Bremse OE numbers 1194194, 1194410, LP4857.
