1300 110 002 Volvo Compatible Twin Cylinder Compressor

What does a twin cylinder compressor do?

This twin cylinder air compressor serves as a critical component within the air brake system of heavy commercial vehicles, providing the necessary compressed air for braking and pneumatic operations. Engineered with two piston-cylinder assemblies, it delivers higher air output than single-cylinder units, ensuring rapid reservoir filling and consistent pressure for heavy-duty braking requirements.

Vehicle and engine compatibility

This unit is compatible with Volvo F10, F12, F7, N10, N12, B10M, and B12 trucks, specifically designed to work with TD70, TD71, TD100, TD101, TD120, TD121, and TD122 engines. It is an OE-equivalent component for Knorr-Bremse and Volvo systems.

Technical specifications and cooling

The compressor features a water-cooled design to manage operating temperatures effectively during intensive use. Technical specifications include a 440cm³ swept volume, M26x1.5 air inlet and outlet ports, and M16x1.5 water inlet/outlet ports. The through-drive configuration ensures efficient power transfer from the engine.

Maintenance and installation guidance

For optimal performance, technicians should inspect the water cooling lines and port connections during every service interval to prevent leaks or overheating. Maintaining clean coolant flow is vital for the longevity of the internal valve plate and piston assemblies.

OE cross-reference

1300 110 002 (Twin Cylinder Compressor) is the equivalent of the Knorr-Bremse and Volvo OE numbers. This part directly replaces Knorr-Bremse OE numbers I90499000, I90499AT000, I90499ES, I90499X00, LP4813. It also replaces Volvo OE numbers 1613632, 5003336.
