4152010 Brake Caliper Bellows Seal for MAN
| Caliper | |
|---|---|
| EAN Code | 8683457024304 |
Ready to Order
Summary
This brake bellows seal is designed for heavy commercial vehicle air disc brake calipers. It ensures a reliable seal for Renault Trucks, MAN, and PACCAR braking systems. Manufactured with high-strength components to withstand demanding service conditions. Equivalent to OE MAN 35503075642, Meritor 68323746PK10 and PACCAR 868304.
What's in this kit
Compatible OEM Codes
-
MAN
- 81.50901.0015
- 81.50901-0015
- 35.50307.5642
- 35.50307-5642
-
ZF
- 0501 322 343
-
RENAULT TRUCKS
- 5006028416
-
PACCAR
- 868304
-
MERITOR
- 68323746PK10
Description
What does a brake bellows seal do?
This brake bellows seal serves as a critical protective component within the air disc brake caliper assembly. By maintaining the integrity of the pneumatic movement, it prevents contaminants from entering the internal caliper mechanism, ensuring consistent braking performance and longevity of the braking system.Vehicle and engine compatibility
The component is designed to be an equivalent for high-quality parts used in Renault Trucks, MAN, and PACCAR heavy commercial vehicles. It is also suitable for vehicles utilizing systems from Meritor and ZF. This ensures reliable operation across various heavy-duty fleets.Installation and maintenance
During installation, technicians should inspect the caliper shaft and piston area to ensure no debris interferes with the bellows movement. Proper lubrication and correct seating are essential to prevent premature wear of the seal material under high-pressure air conditions.System troubleshooting
Regular inspection of the brake caliper bellows is recommended during routine maintenance intervals to prevent air leaks or uneven brake pad wear.OE cross-reference
4152010 (Brake Bellows Seal) is the equivalent of the MAN, Meritor, PACCAR, Renault Trucks and ZF OE numbers. This part directly replaces MAN OE numbers 35503075642, 35503075642, 81509010015, 81509010015. It also replaces Meritor OE number 68323746PK10, PACCAR OE number 868304, Renault Trucks OE number 5006028416 and ZF OE number 0501322343.Other OEMs
MAN
- 81509010015
- 35503075642
- 81.50901.0015
- 81.50901-0015
- 35.50307.5642
- 35.50307-5642
MERITOR
- 68323746PK10
PACCAR
- 868304
RENAULT TRUCKS
- 5006028416
ZF
- 501322343
- 0501322343
- 0501 322 343
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| MAN | |||
| MERITOR | |||
| PACCAR | |||
| RENAULT TRUCKS | |||
| ZF |
FAQ
What is the function of a brake bellows seal?
The seal protects the internal caliper mechanism from dust, water, and road debris, maintaining the airtight integrity required for pneumatic braking.
Which vehicles are compatible with this seal?
This seal is compatible with Renault Trucks, MAN, and PACCAR heavy commercial vehicles, as well as systems from Meritor and ZF.
How can I identify if the brake bellows needs replacement?
Signs of failure include visible cracks in the bellows material or audible air leaks from the caliper assembly during braking cycles.
Can this part be used in heavy-duty trucks?
Yes, it is engineered using high-strength components specifically for heavy commercial vehicle air disc brake systems.
What are the OE reference numbers of this part?
4152010 directly replaces MAN OE numbers 35503075642, 35503075642, 81509010015, 81509010015. It also replaces Meritor OE number 68323746PK10, PACCAR OE number 868304, Renault Trucks OE number 5006028416 and ZF OE number 0501322343.
